Nokia N70 Repair

The Nokia N70 is a multimedia 3G smart-phone made by Nokia and launched in Q3 2005. The N70 (model N70-1) was released as part of Nokia's N Series of smart phones. The N-Series was Nokia's line of multimedia computers that also released the N90 and N91. It features a rear 2 megapixel camera with built-in flash and a front VGA camera to allow video calling on the front. Some other cool features included: FM radio, Bluetooth, digital music player functionality, and support for 3D Symbian, Java games and other S60 2nd Edition software. It uses the S60 user interface and the Symbian 8.1a operating system which was very technical for its time.

In 2006, Nokia released a Music Edition of the N70-1 model which featured a 1 GB memory card, 3.5 mm audio adapter with remote control, headphones, and a dedicated music button in place of the multimedia key button. They also released a N70-5 model that was developed as a lower cost option that didn't encompass a camera or 3g services. The Nokia N70-5 was marketed and sold mainly in China, Mexico, and Eastern European markets.

Track down problems encountered with your Nokia N70 on our Nokia N70 Troubleshooting Page

• Dual mode WCDMA/GSM and triband GSM coverage on up to five continents (GSM 900/1800/1900 and WCDMA 2100 networks)
• Automatic switching between bands and modes

• Volume: 95.9 cc
• Weight: 126 g
• Length: 108.8 mm
• Width (max): 53mm
• Thickness (max): 24mm

• Main color display: 176x208 pixels, up to 262,144 colors. Automatic brightness control
• Five-way scroll key, two soft keys, application key, edit and clear keys, send and end keys, Multimedia key for instant access to your key application
• Active standby screen
• Operating system: S60 software on Symbian OS

• Up to 22 MB of internal dynamic memory for images, contacts, text messages, multimedia messages, ringing tones, images, video clips, calendar notes, to-do list and applications
• Expandable memory: 64 MB Reduced Size Dual Voltage (1.8/3V) MultiMediaCard (MMC)
• Hot swap slot for easy MMC card insertion and removal

• WCDMA 2100 with simultaneous voice and packet data (PS max speed UL/DL= 128/384kbps, CS max speed 64kpbs)
• EGPRS, class B, multislot class 10 (UL/DL = 118.4/236.8 kbps)
• GPRS, class B, multislot class 10
• Speech codecs: FR, EFR, WCDMA, and GSM AMR
• Transfer data from one S60 device to another

• Nokia Push to talk (PoC)
• Contacts: advanced contacts database with support for multiple phone and e-mail details per entry, also supports thumbnail pictures and groups
• Speed dialing
• Logs: keeps lists of your dialed, received, and missed calls
• Automatic redial
• Automatic answer (works with compatible headset or car kit only)
• Supports Fixed Dialing Number, which allows calls only to predefined numbers
• Conference call

• Java™ and Symbian applications available from Nokia Software Market
• Graphics, icons, animations, logos
• Games: Possibility to download new games
• Ring tones: True Tones, polyphonic tones
• Themes: Possibility to download new themes

• Front: 0.3 Megapixel, 2× digital zoom
• Rear: 2.0 Megapixel with L.E.D Flash, 20× digital zoom

• Battery: Lithium Ion Battery 970mAh BL-5c
• Talk Time: Up to 3.5 hrs
• Stand-by Time: Up to 11 days
