Sony's PlayStation VR2 Teardown
Background & Identification
The PlayStation VR 2 is the second visor for virtual reality designed by Sony. Unlike the first, it has better quality and a greater visual field, it supports intelligent ocular tracing and last but not least has two PlayStation VR2 Sense controllers that allow greater interaction in games.
The reality headset will be sold in bundle and without:
- Only the viewer will cost € 599.99 (549.99 $)
- While the viewer within Bundle Horizon Call of the Mountain will cost € 649.99 (599.99 $)
Technical Specifications
PSVR2 Headset
External Dimensions:
- Weight: 560g
- Dimensions: 187×185×277 mm
Display:
- Method: OLED
- Panel Resolution: 2000x2040 for eye
- Refresh Rate: 90 Hz, 120 Hz
- Field of View: Approximately 110 degrees
- Separation between lenses: Adjustable
Sensors:
- Movement sensor: six-axis movement detection system (three-axis gyroscope, three-axle accelerometer)
- Using sensor: IR proximity sensor
Cameras:
- 4 built-in cameras for viewing the viewer and controller
- IR camera by eye for the detection of the gaze
Feedback:
- Vibration of the headset
Communication with PS5:
- USB Type-C®
Audio:
- Input: integrated microphone
- Output: stereo headphones entry
PlayStation VR2 Sense controllers
- Buttons:
- Right: PS button, Options button, Action buttons (Circle / Cross), R1 button, R2 button, Right Stick / R3 button
- Left: PS button, Create button, Action buttons (Triangle / Square), L1 button, L2 button, Left Stick / L3 button
- Sensing/ Tracking:
- Movement sensor: six-axis movement detection system (three-axle gyroscope + three-axis accelerometer)
- Capacitive sensor: tactile detection of fingers
- IR LED: location detection
- Feedback:
- Trigger Effect (on R2/L2 button), Haptic Feedback (by single actuator per unit)
- Port:
- USB Type-C® port
- Communication:
- Bluetooth® Ver5.1
- Battery:
- Type: Built-in Lithium-ion Rechargeable Battery
- Weight:
- Approx 168g per controller
- Dimensions:
- 137 x 135 x 107mm for controllers
