Front Panel Assembly

Front Panel Assembly

 en

Werkzeuge

Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Background

The Samsung Galaxy S Plus is released in 2011 as an update to the original Galaxy S. While the external features are very similar to the original Galaxy S, the S Plus has updated hardware. It boasts a faster processor, bigger battery, and came with Android 2.3.3 installed.

Specifications

Processor

  • 1.4 GHz Qualcomm Snapdragon MSM8255T
  • Adreno 205 GPU

Memory

  • 512 MB RAM
  • 8/16 GB storage

Display

  • Resolution: 800 x 480 pixels
  • Panel: 4 inch Super AMOLED

Camera

  • Resolution: 5 MP rear with autofocus, VGA front-facing

Battery

  • Capacity: 1650 mAh user-replaceable lithium-ion

Design

  • Dimensions: 4.82 x 2.53 x 0.39 inches
  • Weight: 4.2 oz.

Connectivity

  • Micro-USB 2.0
  • 3.5 mm headphone jack
  • Bluetooth 3.0, aptX, A2DP
  • Wi-Fi 802.11 b/g/n
  • A-GPS
  • Stereo FM radio
  • 2G GSM
  • 3G HSDPA
