Mount
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
For solutions to common problems, check out our troubleshooting page. Samsung SmartCam HD Troubleshooting
Background and Identification
Samsung has produced several different SmartCams, this model, in particular, is SNH-E6413BN. It was released March 24th, 2015 and since then there have been no known recalls.
This Samsung SmartCam comes equipped with several features. You can utilize this camera not only as a high definition security camera but also as a babysitting or dog sitting device.
Device Features
128 Degree Ultra-Wide Angle Lens, Wi-Fi Direct Connection (Direct Setup via Smartphone or PC platform)
Built-in two-way talk, advanced motion, and audio detection
Micro SDXC memory card slot for local storage, email and mobile notification (Max 32GB)
Includes a 16GB micro SD card for starters
Specifications
OS: Linux
Resolution: 1920x1080, 1280x720, 640x360
Max. Framerate: 1080p@30fps
Video Compression Format: H.264, MJPEG
Streaming Capability: Multiple Streaming (Up to 5 Profiles)
Angular Field of View (D/V/H): 128°/ 62°/ 111°
Low Light Performance: 0.3Lux(Color), 0Lux(Black/White)
Day & Night: True D/N Filter
Night vision: IR-LED, 5M
Digital Zoom: 4X
Audio Compression Format: G.711, G726
Audio Communication: 2-Way Audio (Built-in Microphone & Speaker), Half Duplex
Memory Slot: microSDHC (FAT32), Up to 32GB
Recording & Playback: Event recording, Manual recording, Continuous recording, Remote playback
Ethernet: RJ-45 (10/100BASE-T)
Wireless: Wi-Fi 802.11 b/g/n (2.4G)
WiFi Direct: Support (Push button)
Security: SSL (AES 256bit)
Max. User Access: 5 users at Unicast Mode
Operating Temperature / Humidity: 0°C ~ +40°C (+32°F ~ +104°F) / Less than 90% RH
Ingress Protection: Indoor
Input Voltage / Current: 9V DC / 1A
Power Consumption: Max. 4.8W
Indication: 1 LED (Power, Status, Link)
Color: White
Dimension (WxHxD): 63.0 x 92.1 x 41.6
Weight: 117g
