Werkzeuge

Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Troubleshooting

If you are having issues with your Sony Xperia Z1s, please refer to the device’s troubleshooting page.

Background and Identification

Device Name

  • Sony Xperia Z1s

Model Number

  • C6916

Release Date

  • January 13, 2014

Distinguishing Features

  • This model has a plastic edge which was implemented to help boost LTE speeds and reception.
  • The notification LED is in a small hole next to the front light sensor.
  • The rear Sony logo is replaced with "Xperia" and the Xperia logo is replaced with T-Mobile branding.
  • A front and rear plastic film is pre-applied to prevent scratches on the glass.
  • It is only available in black and with 32GB internal storage.
  • The headphone jack is at the top edge.

Major Facts

  • This model is a flagship smart phone for Sony. It has a robust design, a very fast processor, and most notably a high quality camera with immense camera features.
  • This was the most impressive smartphone Sony had released at the time, but the display was thought to be inferior to many other smartphones. Although the display was large for its time and had a full HD resolution, its downfall was the lack of IPS technology. This resulted in less than desirable visuals.

Device Recalls

  • The Sony Xperia Z1s was often advertised as waterproof, as was many other Sony Z models. A class action lawsuit was issued against Sony for 24 models of phones including the Xperia Z1s. They reached a settlement that states that if you experienced issues with the water-proofing rating of your phone you are entitled to the following:
    • Warranty extension for up to a year if the device is within warranty period.
    • Warranty extension for up to 6 months if the device is no longer under warranty.
    • Up to 50% of MSRP as refund for compensation if the device is listed among the ones on the Sony lawsuit.
  • To learn more about this, please refer to the following link: ++https://www.xda-developers.com/sony-laws....

Specifications

Body:

  • Dimensions: 145.7 x 73.9 x 8.6 mm (5.74 x 2.91 x 0.34 in)
  • Weight: 162 g (5.71 oz)
  • SIM: Micro-SIM
  • IP58 dust proof and water resistant over 1.5 meter and 30 minutes

Display:

  • Type: TFT
  • Size: 5.0 inches, 68.9 cm2 (~64.0% screen-to-body ratio)
  • Resolution: 1080 x 1920 pixels, 16:9 ratio (~441 ppi density)
  • Protection: Shatterproof glass, Triluminos display, X-Reality Engine

Platform:

  • OS: Android 4.3 (Jelly Bean), upgradable to 5.1 (Lollipop)
  • Chipset: Qualcomm MSM8974 Snapdragon 800 (28 nm)
  • CPU: Quad-core 2.2 GHz Krait 400
  • GPU: Adreno 330

Memory:

  • Card slot: microSDXC (dedicated slot)
  • Internal: ​​32GB 2GB RAM, eMMC 4.5

Main Camera:

  • Single: 20.7 MP, 1/2.3", AF
  • Features: LED flash, HDR, panorama
  • Video: 1080p@30fps, HDR

Selfie Camera:

  • Single: 2 MP
  • Video: 1080p@30fps

Sound:

  • Loudspeaker: yes
  • 3.5mm jack: yes

Communications:

  • WLAN: Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot
  • Bluetooth: 4.0, A2DP
  • GPS: Yes, with A-GPS, GLONASS
  • NFC: yes
  • Radio: Stereo FM radio, RDS
  • USB: microUSB 2.0 (MHL TV-out), USB On-The-Go; magnetic connector

Features:

  • Sensors: Accelerometer, gyro, proximity, compass
  • ANT+

Battery:

  • Type: Li-Ion 3000 mAh, non-removable
  • Stand-by: Up to 600 h (2G) / Up to 620 h (3G)
  • Talk time: Up to 15 h (2G) / Up to 15 h (3G)
  • Music play: Up to 40h

Miscellaneous:

  • Colors: Black
  • Models: C6916
  • SAR: 0.72 W/kg (head)     1.25 W/kg (body)
