Background and Identification

Starting at the same price as last year’s iPhone 11 Pro, Apple’s new flagship sports a completely new design with double the starting storage capacity. The entire lineup gains a flat stainless steel design with smaller bezels, 5G, and a magnetic “MagSafe” charging system. The iPhone 12 Pro also gets a new, larger 6.1-inch “Super Retina XDR” OLED display—compared to the iPhone 11 Pro’s 5.8-inch display. It also ships with a Lightning to USB-C cable—but no power adapter or EarPods (a first for Apple). In addition to updated Silver and Gold finishes, new “Graphite” and “Pacific Blue” color options are available.

The most often replaced iPhone 12 Pro parts include the battery, screen, speakers, and lenses.

Specifications

Announce date: October 13, 2020

Operating System: iOS 14

Display:

  • 6.1-inch “Super Retina XDR” OLED display
  • Ceramic Shield glass technology
  • Haptic Touch
  • 2532 × 1170 pixel resolution (460 ppi)
  • 2,000,000:1 contrast ratio (typical)
  • True Tone
  • P3 wide color gamut
  • 800 nits max brightness; 1200 nits max HDR (typical)
  • Fingerprint-resistant oleophobic coating

Triple primary camera:

  • True Tone flash with Slow Sync
  • LiDAR scanner
  • Apple ProRAW
  • 4K 10-bit HDR video recording with Dolby Vision HDR, up to 60 fps
  • 4x optical zoom range
  • Wide-angle module
    • 12 MP
    • ƒ/1.6 aperture
    • Optical image stabilization (OIS)
    • Autofocus with 100% Focus Pixels
    • Seven-element lens
  • Ultra-wide module (120° field of view, 2x optical zoom out)
    • 12 MP
    • ƒ/2.4 aperture
    • Five-element lens
  • Telephoto module (2x optical zoom in)
    • 12 MP
    • ƒ/2.0 aperture
    • Optical image stabilization (OIS)
    • Six-element lens
    • 52-mm equivalent

TrueDepth selfie camera with Face ID:

  • 12 MP
  • ƒ/2.2 aperture
  • HDR video recording with Dolby Vision, up to 30 fps
  • 4K video recording, up to 60 fps
  • Retina Flash

Processor: A14 Bionic with Neural Engine

  • 5 nm process
  • 6-core CPU
  • 4-core GPU

RAM: 6 GB

Storage: 128, 256, or 512 GB

Battery: 2815 mAh

  • Up to 17 hours of video playback
  • Up to 65 hours of audio playback
  • MagSafe wireless charging, up to 15W
  • Qi wireless charging, up to 7.5W
  • Fast-charge capable

Sensors:

  • Face ID
  • LiDAR scanner
  • Barometer
  • Three-axis gyro
  • Accelerometer
  • Proximity sensor
  • Ambient light sensor

Wireless Connectivity:

  • 802.11ax Wi‑Fi 6 with 2x2 MIMO
  • 5G (sub‑6 GHz; mmWave only on bands n260 and n261 / US models A2172 and A2176)
  • Gigabit LTE with 4x4 MIMO and LAA
  • Bluetooth 5.0
  • Apple-designed U1 Ultra Wideband chip for spatial awareness
  • NFC

Dimensions: 5.78 × 2.82 × 0.29 in (146.7 × 71.5 × 7.4 mm)

Weight: 187 g (6.60 oz), 189 g (6.66 oz) mmWave model

Water Resistance: IP68

Colors: Silver, Graphite, Gold, Pacific Blue
