Werkzeuge

Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Details

Troubleshooting

For additional help on the Acer Aspire Laptop M5-583P-6423, check out the device's troubleshooting page.

Background and Identification

The Acer Aspire M5-583P-6423 is a fairly thin (measuring 0.9″ in height) and elegant silver notebook PC. This Acer laptop model packs a competent Intel Core i5-4200U dual-core processor. When this laptop was first presented in 2014, this processor was considered very powerful. Furthermore, the Acer Aspire M5-583P-6423 carries an Intel HD 4200 non-gaming integrated graphics, 6GB of RAM and a 500GB hard drive.

This laptop uses a full-size keyboard that comes with a numeric pad and a track-pad with integrated buttons to be used as a mouse. Additionally, its screen supports touchscreen technology, which offers versatility and a much more convenient use. This laptop comes with back-light keyboard, making it ideal for use in dark areas. Bluetooth technology is supported for different type of peripherals. It’s important to mention that a DVD burner is not present on this model.

The Acer Aspire M5-583P-6423 presents most ports and slots on its rear side (instead of the usual left or right edge common in other laptops). There are a total of three USB ports and an HDMI video output port for users that wish to display multimedia on a separate HD monitor. Lastly, it comes with a 4-cell lithium polymer battery that can last up to 6.5 hours (depending on the power settings the user chooses).

Specifications

Dimensions

  • Width: 15”
  • Depth: 10.1”
  • Height: 0.9”
  • Weight: 5.3lbs

Processor

  • Name: Intel Core i5-4200U
  • Clock Speed: 1.6GHZ
  • Cores: 2
  • CPU Cache: 3MB

Hard Drive

  • Type: HDD
  • Storage Amount: 500GB

RAM (Memory)

  • Type: DDR3
  • Amount: 6GB
  • Bays: 2

Battery

  • Type: 4-cell lithium ion
  • Life: up to 8 hours

Display

  • Screen Size: 15.6”
  • Touchscreen: Yes
  • Wide Screen Support: Yes
  • Resolution: 1366x768

Misc

  • Operating System: Windows 8
  • Webcam: Yes

Additional Information
