Asus X54C / X54H Repair

Launched in 2012, the Asus X54C is a budget laptop with a 15.6 inch display. Powered by the Intel Core i3 processor in many variations, the X54C is also available with the Intel Pentium Dual-Core Processor as well as the Intel Celeron Dual-Core Processor.

Moreover, the X54C has a .3MP camera, DL DVD±RW/CD-RW, 802.11b/g/n Wireless LAN, and 6-cell lithium ion battery. As a midrange laptop, the X54C is designed for basic daily tasks such as web browsing and checking emails.

• Processor:
  • Intel® Core™ i3 Processor
  • Intel® Pentium® Dual-Core Processor
  • Intel® Celeron® Dual-Core Processor
• Operating System:
  • Windows 7 Home Premium
  • Windows 7 Home Basic
  • This version contains all product updates (SP1)
• Chipset: Intel® HM65 Express Chipset
• Memory: DDR3 1333 MHz SDRAM *¹
• Display: 15.6" 16:9 HD (1366x768) LED Backlight
• Graphic: Integrated Intel® HD Graphics 3000 (Core i3/i5/i7)
• Storage: 2.5" SATA
• Optical Drive:
  • Super-Multi DVD
  • Blue-ray reader
• Card Reader: 4 -in-1 card reader ( SD/ MS/ MS Pro/ MMC)
• Camera: 0.3 Mega Pixel web camera
• Networking:
  • Integrated 802.11 b/g/n
  • Built-in Bluetooth™ V2.1+EDR (Optional)
  • 10/100/1000 Base T
• Interface
  • 1 x Microphone-in jack
  • 1 x Headphone-out jack (SPDIF)
  • 1 x VGA port/Mini D-sub 15-pin for external monitor
  • 1 x USB 3.0 port(s)
  • 1 x USB 2.0 port(s)
  • 1 x RJ45 LAN Jack for LAN insert
  • 1 x HDMI
• Audio:
  • Built-in Speakers And Microphone
  • Altec Lansing® Speakers
• Battery: 4Cells 2600 mAh 37 Whrs
• Power Adapter:
  • Output: 19 V DC, 3.42 A, 65 W
    Input: 100 -240 V AC, 50/60 Hz universal
• Dimensions: 37.8 x 25.3 x 3.56 ~3.72 cm (WxDxH)
• Weight: 2.6 kg (with 4 cell battery)
• Manufacturer Warranty:
  • 2-year limited International hardware warranty. *different by country
    On-line problem resolution through web interface (BIOS, Driver update)
    OS (Windows® 7 ) install/uninstall consultation
    Bundled software install/uninstall consultation
    ASUS software supporting
• Note*¹:
  • DDR3 1333 MHz SDRAM, 2 GB, OnBoard Memory, 1 x SO-DIMM socket for expansion up to 6 GB SDRAM
  • DDR3 1333 MHz SDRAM, 4 GB, OnBoard Memory, 1 x SO-DIMM socket for expansion up to 8 GB SDRAM
