Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
If you are experiencing any form of defects in regards to the Dell Chromebook 3100, refer to the associated troubleshooting page.
Background and Identification
Released in 2019, the Dell Chromebook 3100 laptop was developed by Dell and uses the Chrome OS operating system. Due to its long battery life and sturdier design, this laptop has been marketed towards school students.
An 11-inch 2-in-1 with best-in-class durability and up to 13 hours of battery life empowers students to learn and collaborate.
Major Features
- Water-resistant
- Drop tested against MIL-STD standards
- Reinforced ports
Major Components
- Intel® Dual Core™ Celeron®
- LTE WWAN* (CAT 9)
- Corning® Gorilla® Glass NBT™ on the touch displays
How to identify
- Matte black chassis
- 11.6-inch display
- 360 degrees screen rotation
- Rounded rubberized corners
- Model Number near the middle on the bottom side of the laptop
The underside of the laptop should specify what laptop it is. If it says “Chromebook 3100”, then you’re in luck. Ensure that the repair guides match the model of the laptop.
Technical Specifications
Device Name: Dell Chromebook 3100 2-in-1
Model #: P30T
Release Year: 2019
Display: 11.6 in 1366x768 - Touchscreen
CPU: Intel(R) Celeron(R) N4020 CPU @ 1.10 GHz (2 threads, 2.80 GHz)
Weight: 3.10 lbs.
Height: 0.82”(20.8mm)
Width: (11.96” (303.9mm)
Depth: 8.19” (207.9mm)
Ports:
2 USB 3.1 Gen 1
2 USB Type-C™
1 Wedge-Shaped Lock Slot
1 Power Button
1 Micro SD Memory card reader
1 Headphone/Microphone Combo Jack
1 Volume Button
Battery: Primary 3-Cell 42WHr Battery
Wireless: Intel® Dual Band Wireless AC 9560 (802.11ac) 2x2 + Bluetooth 5.0
