Background and Identification
The Dell Inspiron 1520 is a 15.4-inch laptop computer sold as part of the Inspiron line. Dell Inspiron computers are made by Dell, an American multinational computer technology company, as an affordable line of computers. They come in laptops, desktops, and all-in-one computers. They were originally released in the mid-1990s in the U.S. and marketed as a home office/consumer line of computers.
The Dell Inspiron 1520 model’s 15.4-inch display has a resolution of 1440 by 900 pixels. The screen is classified as a WXGA display, or wide XGA, meaning it is appropriate for business but can also be used for watching movies. The 1520 model includes an Intel Core 2 Duo T5550 dual-core processor with a 2 MB cache. The computer is sold with 2 GB of RAM, though it can support up to 4 GB with two RAM slots. Its hard disk drive (HDD) has a capacity of 160 GB. Its Intel GMA X3100 graphics processor features Dynamic Video Memory Technology 4.0.
The Dell Inspiron 1520 features an 8-in-1 card reader that supports flash memory like the Memory Stick, Memory Stick PRO, MultiMediaCard, SD Memory Card, and xD-Picture Card. This model is sold with a 56-Watt-hour six-cell lithium-ion battery. It was sold in a midnight blue body color with the name “Dell” printed in capital letters inside a circle in the center of the computer’s back cover. The name “Dell” is also printed in capital letters in the center of the computer’s bottom bezel.
Technical Specifications
GENERAL:
- Notebook type: Budget, Mid-size laptops (6-7.5 lbs.)
- Screen type: Widescreen
- Manufacturer: Dell, Inc.
PROCESSOR / CHIPSET:
- CPU: Intel Core 2 Duo T5550 / 1.83 GHz
- Number of Cores: Dual-Core
- Cache: L2 - 2 MB
- 64-bit Computing: Yes
- Data Bus Speed: 667 MHz
- Chipset Type: Mobile Intel GM965 Express
CACHE MEMORY:
- Type: L2 cache
- Installed Size: 2 MB
STORAGE:
- Interface: Serial ATA-150
- Optical Drive: DVD±RW fixed
- Type: none
- Type: Standard
RAM:
- Memory Speed: 667 MHz
- Technology: DDR II SDRAM
- Installed Size: 2 GB
MEMORY:
- Max Supported Size: 4 GB
- Technology: DDR2 SDRAM
- Speed: 667 MHz
- Slots Qty: 2
ENVIRONMENTAL PARAMETERS:
- Humidity Range Operating: 10 - 90%
DISPLAY:
- Resolution: 1440 x 900 (WXGA+)
- Widescreen Display: Yes
- Diagonal Size (metric): 39.1 cm
- Display Resolution Abbreviation: WXGA+
HARD DRIVE:
- Spindle Speed: 5400
- Type: HDD
- Installed Qty: 1
- Capacity: 160 GB
AUDIO & VIDEO:
- Graphics Processor: Intel GMA X3100
- Memory Allocation Technology: Dynamic Video Memory Technology 4.0
- Sound: Stereo speakers
INPUT:
- Type: keyboard, touchpad
COMMUNICATIONS:
- Wireless Protocol: 802.11g
- Wireless Controller: Dell Wireless 1395
- Wired Protocol: 10/100 Ethernet
OPTICAL STORAGE:
- Drive Type: DVD-Writer
- Type: DVD±RW
- Form Factor: fixed
PROCESSOR:
- CPU Type: Core 2 Duo
- Processor Number: T5250
- Manufacturer: Intel
- Clock Speed: 1.83 GHz
FLOPPY DRIVE:
- Type: none
CARD READER:
- Type: 8 in 1 card reader
- Supported Flash Memory: Memory Stick, Memory Stick PRO, MultiMediaCard, SD Memory Card, xD-Picture Card
BATTERY:
- Capacity: 56 Wh
- Cells: 6-cell
- Technology: Lithium-ion
AC ADAPTER:
- Input: AC 120/230 V (50/60 Hz)
CONNECTIONS & EXPANSION:
- Slots
- 2 x memory
- 1 x ExpressCard/54 (1 free)
- Interfaces
- 4 x USB 2.0 4 pin USB Type A
- 1 x display / video - S-video output - 7 pin mini-DIN
- 1 x IEEE 1394 (FireWire) 4 pin FireWire
- 1 x display / video - VGA - 15 pin HD D-Sub (HD-15)
- 1 x network - Ethernet 10Base-T/100Base-TX - RJ-45
- 1 x modem - phone line - RJ-11
- 1 x microphone - input - mini-phone 3.5 mm
- 1 x audio - line-out/headphones - mini-phone stereo 3.5 mm
- Memory Card Reader: 8 in 1 (SD Card, Memory Stick, Memory Stick PRO, MultiMediaCard, xD-Picture Card)
HEADER:
- Brand: Dell
- Product Line: Dell Inspiron
- Model: 1520
- Compatibility: PC
NETWORKING:
- Max Transfer Rate: 56 Kbps
- Data Link Protocol: Ethernet, 802.11a/b
- Wireless LAN Supported: Yes
- Wireless NIC: Dell Wireless 1395
MISCELLANEOUS:
- Color: midnight blue
- Features: Security lock slot (cable lock sold separately)
MONITOR:
- Diagonal Size: 15.4
SOFTWARE:
- Microsoft Office Preloaded: Includes a pre-loaded image of select Microsoft Office 2010 suites. Purchase an Office 2010 Product Key Card or disc to activate preloaded software on this PC.
SYSTEM:
- Notebook Type: notebook
- Platform: Windows
- Hard Drive Capacity: 160 GB
DIMENSIONS & WEIGHT:
- Width: 14.1 in
- Depth: 10.6 in
- Height: 1.7 in
AUDIO OUTPUT:
- Compliant Standards: High Definition Audio
MAINBOARD:
- Data Bus Speed: 667 MHz
- Chipset Type: Mobile Intel GM965 Express
PHYSICAL CHARACTERISTICS:
- Weight: 6.61 lbs
POWER:
- Min Operating Temperature: 32 °F
- Max Operating Temperature: 95 °F
OPERATING SYSTEM / SOFTWARE:
- OS Provided: Type: Vista Home Premium, Microsoft Windows Vista
- Type: Drivers & Utilities
VIDEO OUTPUT:
- Graphics Processor: Intel Graphics Media Accelerator X3100
- Graphics Processor Series: Intel GMA
VIDEO MEMORY:
- Memory Allocation Technology: Dynamic Video Memory Technology 4.0
SERVICE & SUPPORT DETAILS:
- Component: Battery, Display
- Type: Limited warranty, Technical support
- Location: Pick-up and return
- Full Contract Period: 1 year
