Background and Identification

The Dell Inspiron 15 5576 Gaming is a 15-inch laptop computer made by Dell. This laptop is designed for gaming with an AMD processor and a cooling system designed for uninterrupted gameplay.

The Dell Inspiron 15 5576 Gaming laptop runs on the Windows 10 Home 64-bit Edition operating system. It features an AMD A10 9630P quad-core processor with a maximum turbo speed of 3.3 GHz. The processor features a 2 MB cache. This model is sold with 8 GB of RAM, though the laptop can support up to 32 GB of RAM with two RAM slots. The laptop features 1 TB of hard-disk drive storage. The AMD Radeon RX 460 graphics processor features MaxxAudio Pro with stereo speakers, a subwoofer, and a dual-array microphone. The laptop is sold with a 74-Watt-hour 6-cell lithium-ion battery.

The Dell Inspiron 15 5576 Gaming laptop’s 15-inch display features an LED backlight and an anti-glare coating. The computer also includes a touchpad centered with the keyboard’s touchpad

To identify this laptop, look on the bottom cover for a sticker containing either the service code or service tag. These two numbers are unique codes that you can enter on the Dell support website to find the exact name for your device.

Technical Specifications

GENERAL:

  • Operating System: Windows 10 Home 64-bit Edition
  • Manufacturer: Dell, Inc.

PROCESSOR / CHIPSET:

  • CPU: AMD A10 9630P / 2.6 GHz
  • Max Turbo Speed: 3.3 GHz
  • Number of Cores: Quad-Core
  • Cache: 2 MB
  • 64-bit Computing: Yes

CACHE MEMORY:

  • Installed Size: 2 MB

RAM:

  • Memory Speed: 2400 MHz
  • Technology: DDR4 SDRAM
  • Installed Size: 8 GB

MEMORY:

  • RAM: 8 GB
  • Max Supported Size: 32 GB
  • Technology: DDR4 SDRAM
  • Speed: 2400 MHz
  • Form Factor: SO-DIMM 260-pin
  • Slots Qty: 2

ENVIRONMENTAL PARAMETERS:

  • Humidity Range Operating: 10 - 90% (non-condensing)

DISPLAY:

  • LCD Backlight Technology: LED backlight
  • Widescreen Display: Yes
  • Monitor Features: anti-glare
  • Type: LED
  • Diagonal Size (metric): 39.487 cm
  • Display Resolution Abbreviation: Full HD

HARD DRIVE:

  • Spindle Speed: 5400 rpm
  • Type: HDD
  • Capacity: 1 TB

AUDIO & VIDEO:

  • Graphics Processor: AMD Radeon RX 460
  • Sound: Stereo speakers, subwoofer, dual array microphone
  • Audio Codec: Realtek ALC3246
  • Features: MaxxAudio Pro

INPUT:

  • Type: keyboard, touchpad

COMMUNICATIONS:

  • Wireless Protocol: 802.11a/b/g/n/ac, Bluetooth 4.1
  • Wired Protocol: Gigabit Ethernet

OPTICAL STORAGE:

  • Drive Type: no optical drive
  • Type: none

PROCESSOR:

  • CPU Type: A10
  • Processor Number: A10-9630P
  • Manufacturer: AMD
  • Clock Speed: 2.6 GHz

CARD READER:

  • Type: 2 in 1 card reader
  • Supported Flash Memory: MultiMediaCard, SD Memory Card

BATTERY:

  • Capacity: 74 Wh
  • Cells: 6-cell
  • Technology: lithium-ion

AC ADAPTER:

  • Input: AC 120/230 V (50/60 Hz)
  • Output: 130 Watt, 19.5 V, 6.7 A

CONNECTIONS & EXPANSION:

  • Interfaces
    • 2 x USB 3.0
    • HDMI
    • Headphone/microphone combo jack
    • USB 3.0 (PowerShare)
    • LAN
  • Memory Card Reader: 2 in 1 (SD Card, MultiMediaCard)

HEADER:

  • Brand: Dell
  • Product Line: Dell Inspiron
  • Model: 15 5576 Gaming

NETWORKING:

  • Data Link Protocol: Bluetooth 4.1, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

MISCELLANEOUS:

  • Color: black
  • Included Accessories: power adapter
  • Theft/Intrusion Protection: Security lock slot (cable lock sold separately)

MONITOR:

  • Diagonal Size: 15.6 in

SYSTEM:

  • Notebook Type: notebook
  • Platform: Windows
  • Hard Drive Capacity: 1 TB

DIMENSIONS & WEIGHT:

  • Width: 15.1 in
  • Depth: 10.4 in
  • Height: 1 in

PHYSICAL CHARACTERISTICS:

  • Weight: 5.67 lbs

POWER:

  • Min Operating Temperature: 32 °F
  • Max Operating Temperature: 95 °F

OPERATING SYSTEM / SOFTWARE:

  • OS Provided: Type: Windows 10 Home 64-bit Edition

VIDEO OUTPUT:

  • Graphics Processor: AMD Radeon RX 460
  • Graphics Processor Series: AMD Radeon RX

VIDEO MEMORY:

  • Technology: GDDR5 SDRAM
  • Installed Size: 4 GB

INPUT DEVICE:

  • Numeric Keypad: Yes
  • Backlight: Yes

INTERFACES:

  • Comment: PowerShare

SHOCK & VIBRATION TOLERANCE:

  • Shock Acceleration (Operating): 110 g
  • Shock Duration (Operating): 2 ms half-sine pulse
  • Shock Acceleration (Non-operating): 160 g
  • Shock Duration (Non-operating): 2 ms half-sine pulse
  • Vibration Acceleration (Operating): 0.66 g
  • Vibration Frequency Range (Operating): RMS (random)
  • Vibration Acceleration (Non-operating): 1.3 g
  • Vibration Frequency Range (Non-operating): RMS (random)
