Base Cover
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Background and Identification
The Dell Precision 5510 is a mobile workstation laptop released by Dell in 2015 as part of its Precision line of mobile workstations. Dell Precision is a series of mobile and fixed computer workstations designed for professional consumers and CAD/Architecture/CG professionals, or as small-scale business servers. The Precision series was launched in 1997.
The Dell Precision 15 5000 Series (5510) is a 15-inch mobile workstation with a 15.6-inch HD anti-glare light-emitting diode (LED) display. It features an Infinity Display with a very small bezel and an optional resolution of 3840 by 2160 pixels. The Dell Precision 5510 contains an Intel Core Xeon processor and Nvidia Quadro graphics. The laptop includes support for two storage devices, a 2.5-inch 500 GB up to 1 TB hard disk drive, and a solid-state drive available in 256 GB, 512 GB, or 1 TB sizes. It includes either a 56 Whr or 84 Whr Lithium-Ion polymer battery. A review of the Dell Precision 5510 from LaptopMag found that it has modest battery life but a very fast solid-state drive.
The Dell Precision 5510 features a carbon fiber palm rest and a touchpad. It includes an SD card reader port, a Thunderbolt 3 port, two USB 3.0 ports with PowerShare, a headphone/microphone combination jack, an HDMI port, and a battery life indicator.
Technical Specifications
Model: 5510
Processors:
- Intel Core Xeon E3-1505M v5 Quad Core Xeon 2.80GHz, 3.70GHz Turbo, 8MB 45W
- Intel Core i7-6820HQ Quad Core 2.70GHz, 3.60GHz Turbo, 8MB 45W
- Intel Core i7-6700HQ Quad Core 2.60GHz, 3.50GHz Turbo, 6MB 45W
- Intel Core i5-6440HQ Quad Core 2.60GHz, 3.50GHz Turbo, 6MB 45W
- Intel Core i5-6300HQ Quad Core 2.30GHz, 3.20GHz Turbo, 6MB 45W
Operating Systems:
- Windows™ 7 Pro (64-bit)
- Windows™ 10 Pro (64-bit)
- Windows™ 10 Home
- Canonical Ubuntu 14.04 SP1
Chipset: Mobile Intel CM236
Memory: 2 DIMM slots: up to 32GB DDR4 2133MHz
Graphics:
- 3 NVIDIA Quadro M1000M with 2GB GDDR5 dedicated memory
- Intel® Pro Graphics 530 & P530
Display Options:
- 15.6" UltraSharp™ FHD IPS (1920x1080) Wide View Anti-Glare LED-backlit with Premium Panel Guarantee (72% color gamut)
- 15.6" UltraSharp™ PremierColor UHD IGZO (3840x2160) Touch Wide View LED-backlit with Premium Panel Guarantee (100% Minimum Adobe color gamut)
Storage Options:
* Support for two storage devices: one M.2 PCIe NVMe solid state drive and one 2.5" SSD/HDD drive: Dell Fast Response Free Fall Sensor standard
- Hard Disk Drive (HDD): 2.5” 500GB 7200RPM up to 1TB 2.5” 5400RPM SATA 6Gb/s
- Solid State Drive (SSD): 256GB, 512GB, 512GB SED, 1TB 2.5” SATA 6Gb/s
- M.2 PCIe NVMe Solid State Drive (M.2 SSD): 256GB, 512GB, 512GB SED, 1TB SSD
Communication Options:
- Wired: Type C to Ethernet adapter included
- Wireless LAN: Intel® 8260 Dual-Band 2x2 802.11 ac (Miracast) Bluetooth® 4.1
- Dell DW1820 2x2 801.11ac + Bluetooth 4.1
Multimedia:
- Dual integrated high quality speakers and dual integrated noise cancelling digital array microphones standard
- MaxxAudio® Pro by Waves
- Integrated light sensitive HD video webcam
I/O Ports and Connectors:
- SD Card Reader (SD, SDHC, SDXC, supporting up to 64GB)
- 1 x Thunderbolt 3
- 2 x USB 3.0 with PowerShare
- 1 x Headphone and microphone combo jack
- 1 x HDMI
- 1 x battery life indicator
Security:
- Intel® Platform Trust Technology, Trusted Platform Module (TPM) 1.2/2.0, Chassis lock slot support
- Support for optional Computrace8
Dimensions:
- Width X = 14.06” (357.23mm)
- Depth Y= 9.27” (235.47mm)
- Height Z= front 0.45” (11.48mm) – rear 0.66” (16.82mm)
Battery 56Whr Lithium Ion polymer battery 84Whr Lithium Ion polymer battery
Weight: 1.78kg (3.93lb) with FHD non-touch panel and SSD
Power Adaptor: 130 Watt AC adapter (4.5mm barrel)
Regulatory and Environmental Compliance: ENERGY STAR 6.1; EPEAT registered T
AA Configurations available: YES
