Back Panel
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
If you are having difficulties with the Gateway LT2514u, try referring to the troubleshooting page.
Background and Identification
The Gateway LT2514u, is a netbook that is packaged and sold by Acer. Launched in 2010 it was powered by Intel Atom N450 with Windows XP as its primary system. It is black in color and weighs 2.43 lbs with the physical dimensions of 10.17” x 0.94” x 7.24”.
The Gateway LT2514u comes with 1 GB of RAM from the factory. However, it has the ability to hold 2 GB of ram. You can do the upgrade by following our replacement guide.
The Gateway LT2514U comes with a 160GB of storage place. However you can purchase replacement hard disk drives with up to 1TB capacity. If you want to replace the HDD yourself, you can follow our replacement guide.
Specifications
| General | Class | Netbook |
|---|---|---|
| Operating System | Windows XP | |
| Body | Dimensions | 10.17 in x 0.94 in x 7.24 in |
| Weight | 1.10 kg (2.43 lb) | |
| Color | Black | |
| Display | Size | 10.1 inches |
| Processor | Name | Intel Atom N450 |
| Frequency | 1.66 GHz | |
| Cores | 1 per processor | |
| Cache | L1 Cache: 64 kb, L2 Cache: 1 - 2 MB | |
| Architecture | 64-bit | |
| Chipset | Intel NM10 Express | |
| Graphics | Type | Integrated card |
| Name | Intel GMA 3150 | |
| Memory | Capacity | 1 GB (upgradable to 2 GB) |
| Type | PC2-5300/6400 DDR2 200pin SDRAM SODIMM | |
| Storage | Capacity | 160 GB (upgradable to 1 TB) |
| Type | Hard Disc (HDD) | |
| Interface | SATA | |
| Networking | LAN | 100 mpbs |
| Wifi | Yes (802.11b, 802.11g, 802.11n) | |
| Infrared | No | |
| Ports | USB | 3 v2.0 ports |
| VGA | Yes | |
| LAN Ethernet | Yes | |
| ESata | No | |
| FireWire | No | |
| Microphone | 3.5 mm | |
| Headphone | 3.5 mm | |
| Card Reader | SD, MMC | |
| CD/DVD Drive | No | |
| Docking Station Port | No | |
| Devices | Camera | Yes, 1.3 megapixels |
| Microphone | Yes | |
| Battery | Type | Li-Ion |
| Capacity | 4400 mAh | |
| Battery Life | 4 Hours |
