HP EliteBook Folio 1020 G1 Repair

To troubleshoot problems, head to the HP EliteBook Folio 1020 G1 troubleshooting page.

The HP EliteBook Folio 1020 G1 released in 2014 (Model number: N2X53UC) is a fanless laptop featuring an Intel Core M5Y51 processor. It packs 8GB of RAM, up to 512 GB of SSD Storage, and up to 256 GB of self-encrypting drive. This EliteBook comes standard with numerous security-focused software to ensure user safety and privacy.

The standard model of this laptop weighs between 1.22 kg (2.68 lbs) and 1.27 kg (2.81 lbs), depending on whether or not the model includes the touch feature. The ultra light model weighs 1 kg (2.20 lbs). The EliteBook is equipped with an aluminum and magnesium housing with a brushed silver finish to withstand everyday accidents. The EliteBook also comes with two USB 3.0 charging ports, an HDMI port, a 4.5 mm multi-pin AC port, a standard headphone jack, and a micro SD reader slot that is compatible with SD, SDHC, and SDXC.

Dimensions: 310 x 210 x 15.7 mm (12.2 x 8.27 x 0.62 in)

Weight: 1.27 kg (2.81 lbs)

Memory: 8 GB

Battery: HP 4-Cell (36 Whr) polymer long life battery

Processor: Intel Core M-5Y51 1.1 GHz (max turbo frequency 2.6 GHz), 4 MB L3 Cache. 4.5W

Display: 12.5-in diagonal eDP, UltraSlim, FHD UWVA, anti glare (1920 x 1080) 300nts

Keyboard: backlit, Spill-resistant with drain

Power supply: 45-W Smart AC adapter, 65-W Smart EM AC adapter, 65-Slim Smart Adapter

• Two stereo speakers
• HD audio with DTS Studio Sound
• Integrated 720p webcam
• Integrated dual-array microphone

• Integrated wireless local area network (WLAN) options by way of M.2 wireless module.
• Two WLAN antennas built into display assembly.

• Integrated NFC module.
• NFC antenna configured with NFC option.

• Intel UMA Graphics with shared video memory.
• Intel HD Graphics 5300.
