Fans
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
For further help with the InFocus IN3114 Projector, please refer to the device’s troubleshooting page.
Background and Information
The InFocus IN 3114 Projector is an XGA Conference Room Projector released in December 2009 and discontinued by InFocus in March 2013. The projector has the classic vents on either side and comes primarily in the color black. It boasts a large projection lens encircled by its signature blue-light ring. Like most projectors, its 21 navigation buttons are located on the top side of the projector when oriented properly.
The InFocus IN3114 does not host any known recalls on device parts, but like many projectors, dead pixels are a common problem. Fan noise is minimal when operational, though it appears to push air quickly out of the right side.
The projector provides both computer and video connection options and output connector options for different conditions. It introduced internal DLP technology, providing higher contrast, less visible pixels, and portability. At its brightest setting, it can display 3,500 Lumens with a native resolution of 1024 x 768, and this device is 3D capable.
Specifications
Projector
- Size: 4.60" x 12.40" x 9.50" (HxWxD)
- Weight: 7.0 lbs
- Audible Noise: 32 dB / 28 dB
- Internal Speakers: 5.0 Watts × 2
- Power: 288 Watts 100V - 240V
- Connection Panel: Composite: RCA RS232: DB-9pin
Connection Ports:
- DisplayPort
- S-Video
- HDMI 1.3
- USB
- Network: RJ-45 VGA
- Composite: RCA
- RS232: DB-9 pin
- VGA In: Dsub-15 pin x 2
Lens
- Included Lens: 1.2x manual zoom , manual focus
- Optional Lenses :No
- Lens Shift: No
- Throw Distance: 7.8' - 23.8' Calculate Throw Distance
- Image Size: 60.00" - 220.00"
- Throw Ratio: 1.62:1 - 1.95:1 (D:W)
Lamp
- Type: 280W UHP bulb
- Life: 3,000 hours / 4,000 hours
- Model: SP-LAMP-058
Display
- Brightness: 3,500 ANSI Lumens / 2,800 Lumens
- Resolution: 1024x768
- Contrast: 2,100:1 (full on/off)
- Display Type: 0.60" DLP x 1
- Color Processing: 8-bit
- Video Modes: 1080i, 720p, 576p, 576i, 480p, 480i
- Data Modes: MAX 1920x1200
Additional Information
* Projector Central Specifications
