Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Background and Identification

The Lenovo Yoga 11e Chromebook is a laptop computer majorly used in the educational market. Lenovo Yoga laptops are identifiable by their hinged displays. They include touchscreens that can be rotated around a base, allowing users to interact with the device in a variety of configurations. This means users can experience both the productivity of a laptop and the convenience of a tablet all in one device. Lenovo Yoga laptops also include a keyboard and trackpad. They come in a variety of colors, but they all have the word “YOGA” on the back of the display.

The Lenovo Yoga 11e Chromebook features a 10-point multitouch HD 11.6-inch display with a resolution of 1366 by 768 pixels. The laptop’s display features an antiglare coating and a Corning Gorilla Glass covering for impact- and scratch-resistance. The device is advertised to be able to survive drops from up to three feet because of its rubberized bumpers. It also features a water-resistant keyboard with mechanically-anchored keys.

The Lenovo Yoga 11e Chromebook includes 4 GB of memory and 32 GB of storage with a 720p front-facing camera. The laptop has an array of ports and slots built into its base, including two USB-C ports, one USB 3.0 port, a combination audio/microphone jack, a MicroSD card slot, and a Kensington lock slot.

Technical Specifications

Operating System: Chrome

Processor: Intel® Quad Core™ Celeron® N3450

Display: 11.6" HD IPS, 10-point multitouch touchscreen (1366 x 768 250 nit) antiglare, Corning® Gorilla® glass

Touch Screen: Standard

Battery: Up to 10 hours

Memory: 4 GB LPDDR4

Storage: 32 GB eMMC

WiFi: 802.11 AC (2 x 2 )

Camera: 720p

Keyboard: Full-sized, water-resistant with touchpad & mechanically-anchored keys

Durability Features:

  • Reinforced ports & 360-degree hinges
  • Rubberized bumpers
  • Corning® Gorilla® Glass screen
  • Water-resistant keyboard with mechanically-anchored keys
  • Drop-resistant up to 3 ft / 90 cm

Ports & Slots:

  • 2 x USB-C
  • 1 x USB 3.0
  • Combo mic/audio jack
  • MicroSD card
  • Kensington lock slot

Weight: Starting at 3.5 lbs / 1.59 kg

Dimensions (H x W x D): 300 mm x 210 mm x 23.4 mm / 11.81" x 8.27" x .92"
