Werkzeuge

Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Troubleshooting

If you are experiencing any problems with the Lenovo Yoga Book X90F, check out the Lenovo Yoga Book X90F Troubleshooting Page for help.

Background and Identification

The Lenovo Yoga Book is a lightweight, 2-in-1 laptop and tablet with an Intel Atom x5-Z8550 Processor , released in fall of 2016 and has since been discontinued. The device uses Windows 10 Home as an operating system.

The Yoga Book X90F also comes with a Precision Pen and E Ink panel which can turn into a halo keyboard, and utilizes a special watchband hinge that lets the display move 360 degrees. The Yoga Book X90F differs from the Lenovo Yoga series due to the bottom screen being a touchscreen keyboard that can be turned on and off. The Yoga series has a typical keyboard that you would see on the majority of laptops.

The Yoga Book X90F features a backlit keyboard. It also contains 4 gigabytes of RAM. There is a front facing camera that will be beneficial when conducting meetings via Skype or Microsoft Teams. The battery is a Lithium-Polymer battery that will last up to 8 hours per charge. The biggest additional accessory that could be included with the laptop is Microsoft Office 365.

This design makes it more travel friendly as it is small and lightweight. The E Ink display allows one to type, take notes, and create sketches. This makes it easier for users to take notes during meetings, take quick notes when traveling, or make a quick sketch when visiting a city.

When the Lenovo Yoga Book X90F was discontinued, it was replaced with 2-in-1 Tablets.

Specifications

Dimensions: 6.72 x 10.10 x 0.38 inches (170.8 x 256.6 x 9.6mm; W x D x H)

Weight: 1.52 lbs (690 g)

Webcam: 8-megapixel back with auto-focus, 2-megapixel front

CPU: Intel Atom x5-Z8550 Processor (2M Cache, Quad-Core, Up to 2.4 GHz)

Storage: 64 GB internal

Battery: 8500 mAH, up to 13 hours use

Graphics: Intel HD Graphics 400

Screens: 10.10-inch, 1920 x 1080 pixel, multi-touch with pen connectivity

Additional Info

Lenovo Yoga Book X90F Website

Lenovo Yoga Book X90F Review

Lenovo Yoga Book X90F User Guides
