Background and Identification

The Mi-T-M model CM-1400-HDEC1 is an electric pressure washer that is designed for light-duty projects such as cleaning patio furniture, screens, lawn care equipment, and vehicles. This model is more useful for lighter jobs where a gasoline-powered pressure washer is not practical. It can produce a stream of water with a pressure of up to 1400 pounds per square inch (PSI) and a flow rate of 1.5 gallons of water per minute (GPM).

The Mi-T-M Pressure Washer CM-1400-HDEC1 includes a 50-foot by 3/8-inch hose, a trigger gun, and a 36-inch lance. It also includes 15-degree, 25-degree, and detergent quick-connect hose nozzles. The pressure washer includes built-in low-pressure detergent injection. It is powered by an enclosed 1.5-horsepower fan-cooled electric motor with manual reset thermal overload protection. The CM-1400-HDEC1 model includes a 35-foot power supply cord with a ground fault circuit interruption (GFCI) and a 15-amp plug. The pressure washer also features an in-line water strainer.

The CM-1400-HDEC1 model’s mild steel powder-coated frame includes rubber insulators. The pressure washer features an upright tilt-back design. The frame includes two rear wheels and a rounded handle. The name “Mi-T-M” is printed in white font on the front of the pressure washer’s front as well as on the front of the washer’s motor.

Technical Specifications

Specifications:

  • PSI: 1400
  • GPM: 1.5
  • Horsepower/Motor: 1.5 HP, 120V, 1Ø, 13.5A
  • Pump: Triplex Crankshaft
  • Unloader: Adjustable Pressure
  • Plug Type: NEMA 5-15P
  • Lance: 36 in.

Weights and Dimensions:

  • Net Weight: 45.00 lbs.
  • Length: 14.00 in.
  • Width: 11.00 in.
  • Height: 10.00 in.
