Background and Identification

The Microsoft Lumia 435 is a Windows mobile phone introduced by Microsoft Mobile in January 2015. Microsoft Mobile was a subsidiary of Microsoft and primarily manufactured mobile phones. It was established in 2014 after Microsoft acquired Nokia’s Devices and Services division. In the United States, the Lumia 435 was sold for USD$50.

The Microsoft Lumia 435 features a 4.0-inch display with a resolution of 480 by 800 pixels. The phone houses a Micro-SDXC SIM card in a dedicated slot. It comes with 8 GB of internal storage and 1 GB of RAM. Its internal storage can be expanded using the phone’s microSDXC slot. The phone features a 2-megapixel main camera and a VGA selfie camera. The Microsoft Lumia 435 also includes a 1560 mAh removable battery, meaning its battery is not attached to the inside of the phone with any kind of permanent adhesive, making repair and replacement easier than for non-removable batteries.

The Microsoft Lumia 435 includes the Windows three-button navigation system with a ‘home’ button in the center of the phone’s bottom bezel (indicated with four squares that make up a larger square), a ‘back’ button on the left side of the ‘home’ button (indicated with an arrow pointing to the left), and a ‘search’ button on the right side of the ‘home’ button (indicated by a magnifying glass icon).

Technical Specifications

Release date: March 2015

Body:

  • Dimensions and Weight: 118.1 x 64.7 x 11.7 mm (4.65 x 2.55 x 0.46 in), 134.1 g (4.73 oz)
  • SIM: Micro-SIM

Display:

  • Type: IPS LCD
  • Size: 4.0 inches, 45.5 cm2 (~59.6% screen-to-body ratio)
  • Resolution: 480 x 800 pixels, 5:3 ratio (~233 ppi density)

Platform:

  • OS: Microsoft Windows Phone 8.1, upgradable to Windows 10
  • Chipset: Qualcomm MSM8210 Snapdragon 200 (28 nm)
  • CPU: Dual-core 1.2 GHz Cortex-A7
  • GPU: Adreno 302

Memory:

  • Card slot: microSDXC (dedicated slot)
  • Internal: 8GB 1GB RAM
  • eMMC 4.5

Main Camera:

  • Single: 2 MP, f/2.7, 36mm (standard), 1/5.0"
  • Video: 480p@30fps

Selfie Camera:

  • Single: VGA
  • Video: 480p

Sound:

  • Loudspeaker: Yes
  • 3.5 mm jack: Yes

Communications:

  • WLAN: Wi-Fi 802.11 b/g/n, hotspot
  • Bluetooth: 4.0, A2DP
  • GPS: A-GPS, GLONASS
  • NFC: No
  • Radio: FM radio, RDS
  • USB: microUSB 2.0

Features:

  • Sensors: Accelerometer, proximity

Battery:

  • Type: Li-Ion 1560 mAh, removable

Miscellaneous:

  • Colors: Black, White, Green, Orange
  • SAR: 0.81 W/kg (head)     0.53 W/kg (body)
  • SAR EU: 0.58 W/kg (head)     0.54 W/kg (body)
