Nextbook NXA116QC164 Tablet Repair

Released in 2015, the Nextbook Ares 11 NXA116QC164 is an Android tablet laptop with an 11.6 inch IPS display with a resolution of 1366 by 768 pixels. The tablet also includes a detachable POGO LED keyboard. Running the Android 5.0 Lollipop, the Ares 11 comes with 64GB of internal storage that is expandable via the microSD expansion slot. The tablet includes 1 GB of DDR3L RAM. Its storage capabilities make the Nextbook Ares 11 a suitable cross-over between a business machine and an everyday-use device, fit for running games, digital movies, and other applications. Moreover, the Ares 11 comes with both front and rear cameras with 2MP resolution, easing use for school and work. In terms of privacy, assurance is added through the addition of both a microphone and headphone jack.

As a two-in-one device, the Ares 11 has a traditional tablet-hybrid design as the tablet docks into the keyboard using the sustaining ports and the POGO connectors. The plastic keyboard reclines up to 120 degrees, providing users with effective viewing angles. Weighing in at under 4 pounds, the Ares 11 eases portability for users.

The Ares 11 includes a 9000 mAh lithium polymer battery that is advertised to have a run time of up to 10 hours and a recharge time of 4.5 hours. The Nextbook NXA116QC164 table includes Android’s three-button navigation system which includes a house-shaped button as a “home” button in the center of the tablet’s bottom bezel, a rectangle as a “show-all-applications” button on the right of the “home” button, and a “back” button depicted with an arrow pointing to the left.

• Display
  • Touchscreen: Multi-Touch
  • Multi-Touch Display: Yes
  • Technology: TFT active matrix
  • TFT Technology: IPS
  • Diagonal Size: 11.6 in
  • Diagonal Size (metric): 29.5 cm
  • Native Resolution: 1366 x 768
  • Image Aspect Ratio: 16:9
• Features: LED indicator, backlit keyboard compatible
• Color: blue trim
• Color Category: black
• Processor:
  • Clock Speed: 1.8 GHz
  • Number of Cores: Quad-Core
  • Type: Atom
  • Processor Number: Z3735F
  • Manufacturer: Intel
• Storage: 64 GB eMMC
• Communications:
  • Wireless Protocol: 802.11b/g/n, Bluetooth 4.0
• Networking:
  • Wireless Connectivity: Bluetooth 4.0, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
• Multimedia:
  • Audio: Microphone, speaker
• Battery:
  • Run Time (Up To): 10 hour(s)
  • Run Time Details:
    • Audio playback: up to 10 hour(s)
    • Video playback: up to 9 hour(s)
    • Web browsing: up to 9 hour(s)
  • Technology: lithium polymer
  • Capacity: 9000 mAh
  • Recharge Time: 4.5 hour(s)
• RAM:
  • Technology: DDR3L SDRAM
  • Installed Size: 1GB
• Flash Memory: 64 GB. Embedded MultiMediaCard
• OS: Android 5.0 Lollipop
