Background and Identification

The Toshiba Satellite S75D-A7346 is a 17.3" PC laptop by Toshiba in the Satellite series. The Toshiba Satellite (called the Dynabook Satellite in Japan) is a line of consumer notebook computers sold by Toshiba, a Japanese multinational conglomerate headquartered in Tokyo. Toshiba Satellite computers were introduced in the 1990s as some of the earliest laptops to compete with IBM’s Thinkpad line.

The Toshiba Satellite model S75D-A7346 runs on a preloaded Windows 8 operating system. It includes an AMD A10 5750M quad-core processor with a 4 MB cache. The computer is sold with 8 GB of RAM installed as two 4 GB SDRAM chips. The S75D-A7346 model can support up to 16 GB of internal memory and a 1 TB hard drive. It is sold with an AMD Radeon HD 8650G graphics processor and an integrated webcam. This model features a multi-touch touchpad that is centered with the computer’s space bar, which is to the right of the computer base’s center.

Toshiba laptops can be identified by the name “Toshiba” printed in capital letters in the center of the computer’s bottom bezel. To identify the model of a Toshiba laptop, bring up the Start menu on the computer and search for “diagnostic tool.” Running the PC Diagnostic Tool gives users several options, including identifying the laptop’s make and model.

Technical Specifications

GENERAL:

  • Platform Technology: AMD VISION
  • Operating System: Windows 8 (preloaded)
  • Manufacturer: Toshiba

PROCESSOR / CHIPSET:

  • CPU: AMD A10 5750M / 2.5 GHz
  • Max Turbo Speed: 3.5 GHz
  • Number of Cores: Quad-Core
  • Cache: L2 - 4 MB
  • 64-bit Computing: Yes
  • Features: AMD Turbo CORE technology 3.0

CACHE MEMORY:

  • Type: L2 cache
  • Installed Size: 4 MB

RAM:

  • Memory Speed: 1600 MHz
  • Configuration Features: 2 x 4 GB
  • Technology: DDR3 SDRAM
  • Installed Size: 8 GB

STORAGE:

  • Interface: Serial ATA-300
  • Optical Drive: DVD±RW (±R DL) / DVD-RAM fixed
  • Read Speed: 24x (CD) / 8x (DVD)
  • Write Speed: 24x (CD) / 8x (DVD±R) / 6x (DVD±R DL)
  • Rewrite Speed: 16x (CD) / 6x (DVD-RW) / 8x (DVD+RW) / 5x (DVD-RAM)

MEMORY:

  • Max Supported Size: 16 GB
  • Technology: DDR3 SDRAM
  • Speed: 1600 MHz
  • Slots Qty: 2
  • Empty Slots: 0

ENVIRONMENTAL PARAMETERS:

  • Humidity Range Operating: 20 - 80% (non-condensing)

DISPLAY:

  • LCD Backlight Technology: LED backlight
  • Widescreen Display: Yes
  • Image Aspect Ratio: 16:9
  • Monitor Features: TruBrite
  • Type: LED
  • Diagonal Size (metric): 43.9 cm
  • Display Resolution Abbreviation: Full HD

HARD DRIVE:

  • Spindle Speed: 5400 rpm
  • Type: HDD
  • Capacity: 1 TB

AUDIO & VIDEO:

  • Graphics Processor: AMD Radeon HD 8650G
  • Integrated Webcam: Yes
  • Sound: Harman/kardon stereo speakers, microphone

INPUT:

  • Type: keyboard, touchpad
  • Localization & Layout: US
  • Features: multi-touch touchpad

COMMUNICATIONS:

  • Wireless Protocol: 802.11b/g/n, Bluetooth 4.0
  • Wired Protocol: 10/100 Ethernet

OPTICAL STORAGE:

  • Drive Type: DVD SuperMulti
  • Type: DVD±RW (±R DL) / DVD-RAM
  • Form Factor: fixed

PROCESSOR:

  • CPU Type: A10
  • Processor Number: A10-5750M
  • Manufacturer: AMD
  • Clock Speed: 2.5 GHz

CARD READER:

  • Type: card reader
  • Supported Flash Memory: SD Memory Card, SDHC Memory Card, SDXC Memory Card, microSD, miniSD

BATTERY:

  • Capacity: 48 Wh
  • Cells: 6-cell
  • Technology: lithium-ion
  • Run Time (Up To): 4.25 hour(s)

AC ADAPTER:

  • Input: AC 120/230 V (50/60 Hz)
  • Output: 75 Watt, 19 V, 3.95 A

CONNECTIONS & EXPANSION:

  • Interfaces
    • VGA
    • HDMI
    • Microphone input
    • Headphone output
    • LAN
    • USB 2.0
    • 2 x USB 3.0
  • Memory Card Reader: Yes (SD Card, miniSD, SDHC Card, microSD, SDXC Card)

HEADER:

  • Brand: Toshiba
  • Product Line: Toshiba Satellite
  • Model: S75D-A7346
  • Country Kits: United States
  • Compatibility: PC

NETWORKING:

  • Data Link Protocol: Bluetooth 4.0, Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
  • Compliant Standards: Wi-Fi CERTIFIED

MISCELLANEOUS:

  • Color: ice silver with brushed metallic, black keyboard
  • Features: USB Sleep-and-charge ports, security lock slot (cable lock sold separately)
  • Compliant Standards: RoHS
  • Included Accessories: power adapter

MONITOR:

  • Diagonal Size: 17.3 in

SYSTEM:

  • Platform Technology: AMD VISION
  • Notebook Type: notebook
  • Platform: Windows
  • Hard Drive Capacity: 1 TB

DIMENSIONS & WEIGHT:

  • Width: 16.3 in
  • Depth: 10.6 in
  • Height: 1.3 in

AUDIO OUTPUT:

  • Compliant Standards: DTS Studio Sound

MANUFACTURER WARRANTY:

  • Type: 1-year warranty

ENVIRONMENTAL STANDARDS:

  • ENERGY STAR Certified: Yes

PHYSICAL CHARACTERISTICS:

  • Weight: 5.91 lbs

POWER:

  • Min Operating Temperature: 41 °F
  • Max Operating Temperature: 95 °F

OPERATING SYSTEM / SOFTWARE:

  • OS Provided: Type: Windows 8
  • Type: Adobe Reader, DTS Studio Sound, Microsoft Internet Explorer 10, Microsoft Office 365 (30 days trial), Norton Anti-Theft (30 days trial), Norton Internet Security (30 days subscription), Toshiba App Place, Toshiba Book Place, Toshiba Eco Utility, Toshiba HDD Protection, Toshiba HDD recovery, Toshiba Hardware Setup Utility, Toshiba Media Player, Toshiba Recovery DiskCreator, Toshiba Recovery Media Creator, Toshiba Resolution+, Toshiba Service Station, Toshiba Start, Toshiba Video Player, WildTangent Game Console

VIDEO OUTPUT:

  • Graphics Processor: AMD Radeon HD 8650G
  • Graphics Processor Series: AMD Radeon HD

NOTEBOOK CAMERA:

  • Integrated Webcam: Yes

INPUT DEVICE:

  • Numeric Keypad: Yes
  • Backlight: Yes
