VTechCS6719-16 Repair

For more information regarding common troubleshooting issues, check out this link:

VTechCS6719-16 Troubleshooting

The VTechCS6719- 16 is a cordless expandable handset that utilizes DECT 6.0 platform technology. Identifiable by its smooth, rectangular design this phone like others in the family is able to provide superior sound quality and lesser interference from wireless networks. It also can boast an improved range without an increase in power consumption. It often comes with a black upper half and interchangeable color body and base. Because this is part of an expandable handset additional handsets can be added to the network simply without the use of additional phone jacks. The VTechCS6719-16 also boasts some features recognizable in other higher end cordless phones such as ECO mode, caller ID, and silent mode.

Frequency:

DECT 6.0 Digital

Control:

Crystal controlled PLL synthesizer.

Transmit Frequency:

Handset:

1921.536-1928.448 MHz

Telephone Base:

1921.536-1928.448 MHz

Number of Channels:

5

Ideal Range:

Maximum power allowed by FCC and IC. Actual operating range may vary according to environment conditions at the time of use.

Power Requirements:

Handset:

• 2.4V Ni-MH battery
• Telephone base: 6V AC @ 300mA Charger: 6V AC @ 300mA

Memory:

Handset directory:

50 memory locations; up to 30 digits and 15 characters Handset caller ID log: 50 memory locations; up to 24 digits and 15 characters.

User Display Interface:

• Date/Time Display
• Caller ID
• Voicemail waiting indicator
• Trilingual prompts: English, Spanish and French

Settings:

• Mute
• Speakerphone
• Volume control
• Any key answer

Communication Features:

• Conference between an outside line and up to 2 cordless handsets
• Intercom between handsets
• 50 name and number phone-book directory

Additional Features:

• Backlit Keypad
• Backlit LED screen
• 10 possible ringtones
• Wall-mount bracket
• Last 10 number redial

Additional information:

User Manual

Product Website
