ZTE Maven Repair

To diagnose your ZTE Maven’s issues and find links to handy dandy repair guides, visit the ZTE Maven Troubleshooting page.

The ZTE Maven (Model number: z812) was released to the public June, 2015. The phone was created to cater to consumers seeking an accessible and affordable smartphone that’s compatible for their busy and on-the-go life, ZTE Maven provides excellent performance and style.

The phone weighs 4.73 oz and has a black, plastic exterior. It provides a memory capable of holding up to 8GB, but the MicroSD card slot can hold up to 32 GB of memory. The ZTE Maven has a camera of 5MP rear-facing camera and a VGA front-facing camera. The video recorder is 720p.

The ZTE Maven also includes a battery life of up to 360 hours with a talk time of 10 hours. The touchscreen has a display of 4.5” with a resolution of 480 x 854 pixels.

ZTE has released twelve models of the ZTE phone, . The Blade A5 2019 is the latest model released to the public. The newest model has greater resolution with 720x1440 pixels and touch screen availability of 5.45”.

• Dimensions: 5.78 x 2.89 x 0.34
• Weight: 150g
• Non-Removable Li-Ion 2100 mAh battery
• SIM Type: Micro-SIM
• Operating System: Android 5.1 (Lollipop)
• Network: 4G LTE
• Card Slot Memory: microSD, up to 32 GB (dedicated slot)
• WLAN: Wi-Fi 802 /gn, hotspot RAM
• Bluetooth: 4.0, A2DP
• GPS: yes, with A-GPS
• Radio: TBC
• USB: microUSB 2.0

Display Type

• Type: IPS LCD Capacitive touchscreen, 16M color
• Size: 4.5 inches, 55.8 cm² (~62.7% screen-to-body ratio)
• Resolution: 480 x 854 pixels, 16:9 ratio (~218 ppi density)

Memory

• Slot Memory: microSD, up to 32 GB (dedicated slot)
• Internal: 8GB, 1GB

Platform

• OS: Android 5.1(Lollipop)
• Chipset: Qualcomm MSM8916 snapdragon 410 (28)
• CPU: Quad-core 1.2 GHz Cortex-A53
• GPU: Adreno 306

Main Camera

• Single: 5MP
• Features: LED flash
• Video: yes

Selfie Camera

• Single: VGA
• video

Battery

• Non-removable Li-Ion 2100
• Stand-by: Up to 360 h (3G)
• Talk time: Up to 10 h (3G)

Sound

• Loudspeaker: yes
• 3.5mm Jack: yes

Misc

• Colors: Black
• Models: Z812
• Price: About 50 EUR

• Wikipedia: ZTE (The Company)
• ZTE Maven (z812) Manual
• The AT & T Page for the ZTE Maven
