RAM
Tools
These are some common tools used to work on this device. You might not need every tool for every procedure.
Background and Identification
ZOTAC is a Hong Kong-based computer hardware company established in 2006. ZOTAC created their first video card in 2007, and in 2015 they created their first min-gaming computer called NEN. In 2015, they released their ZOTAC EN970, which is their ultimate gaming mini PC.
The ZOTAC EN970 is a black, boxed-shaped mini-computer with the ZOTAC logo in the front in between the large, round power button, and a number of I/O Ports, including an SD/SDHC/SDXC card reader, a USB 3.1 port, a mic, and headphone plugin, and a USB 3.1 type-c port. On the back, the power input is at the far left, with various ports sprawled along the back.
Technical Specifications
Computing System
- Processor: Intel Core i5-5200U Processor(dual core 2.2 GHz, up to 2.7 Ghz)
- Chipset: Intel, NVIDIA
- System Memory: 2 x DDR3L-1600 SODIMM Slots,Max 16GB
Graphics
- Graphics Engine: GeForce® GTX 960
- Video Output: 4 HDMI2.0 (Up to 4K @ 60Hz)
Storage
- Hard Drive: 2 x 2.5" SATA 6Gbps HDD/SSD Slots
- Card Reader: SD/SDHC/SDXC UHS-II
I/O Ports
- Audio: Microphone, Headphone
- USB Port: 4 x USB 3.0 / 2x USB 2.0
- LAN: Dual Gigabit LAN
- Antenna: 1 x WiFI SMA connetor
- Wifi: 802.11ac/b/g/n
- Bluetooth: Bluetooth 4.0
- Legacy I/O: None
- CIR Infrared Port: Yes
- Thunderbolt: None
Mechanical
- Kensington Lock: Yes
- LED Indicators: Power, HDD, WiFi
- Power Supply: AC Adapter O/P: DC 19.5V/180W
- Cooling system: Fan + Heatsink
- ZBOX Dimensions: 210mm x 203mm x 52.5mm
- Case Mounting: None
Miscellaneous
- Supported OS: Windows 10 / 8 / 7 (32/64-bit)
- Accessories
- 1 x WiFi antenna
- 1 x AC Adapter
- 1 x power cord
- 1 x warranty card
- 1 x user manual
- 1 x quick install guide
- 1 x USB drive with O/S driver
- 1 x driver disc
