'On'/'Off' Switch
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
For specific problems, consult the troubleshooting page.
Background and Identification
The Cen-Tech Seven Function Digital Multimeter is an electronic device which measures AC voltage, DC voltage, DC current, resistance, transistor (hFE), diode, and battery charge of other electronic devices. This Multimeter features an easy-to-read 3.5 inch digital LED reading screen, two test leads (one red and one black), an "on"/"off" switch, and a dial which allows users to select a mode of testing.
Cen-Tech Seven Function Digital Multimeter Specifications:
- SKU: 90899
- Automatic zero adjust
- Data hold retains information after test
- Resolution: 3-1/2
- Power requirements: 9V battery
- Frequency: 45 to 450 Hz
- Backlit display: No
- Batteries included: Yes
- Display type: LCD
- Number of functions: 7
- Height: 1 in.
- Length: 5 in.
- Width: 2-11/16 in.
- DC amps: 200mA/2000mA/20mA/10A
- DC voltage: 200mV/2000mV/20/200/1000V
- AC voltage: 200/750V
- Resistance: 200/2000/20K/200K/2000K Ohm
- Color: Red
- Accessories included: two 24 in. test leads
- Warranty: 90 days
Additional Information
For set-up and operating instructions, click here.
For simple step-by-step operation, click here.
For a more detailed explanation of basic usage and procedures, refer to this video.
