Base Panel
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
If you are having issues with the Dell XPS 15 9500, try referring to the troubleshooting page.
Background and Identification
The Dell XPS 15 9500 is a 15” laptop released in 2020. It has a gray metallic body and features a touch screen. There are seven ports on the sides of the aluminum chassis. On the center of the top plate there is a silver Dell logo. The power button is located on the upper right corner of the keyboard.
Specifications
Processor: 10th Generation Intel® Core™ i7-10750H (12MB Cache, up to 5.0 GHz, 6 cores)
Operating System: Windows 10 Home English
Graphics Card: NVIDIA® GeForce® GTX 1650 Ti 4GB GDDR6
Display: 15.6" FHD+ (1920 x 1200) InfinityEdge Non-Touch Anti-Glare 500-Nit Display
Memory: 16GB DDR4-2933MHz, 2x8G
Hard Drive: 256GB M.2 PCIe NVMe Solid State Drive
Color: Platinum Silver exterior, Black interior
Keyboard: English keyboard, black, backlit, Fingerprint Reader
Ports:
- 2x Thunderbolt™ 3 with power delivery & DisplayPort
- 1x USB-C 3.1 with power delivery & DisplayPort
- 1x Full size SD card reader v6.0
- 1x 3.5mm headphone/microphone combo jack
- 1x Wedge-shaped lock slot
- 1x USB-C to USB-A v3.0 & HDMI v2.0 adapter ships standard
Dimensions & Weight:
- Height: 0.71" (18 mm)
- Width: 13.57" (344.72 mm)
- Depth: 9.06" (230.14 mm)
- Starting weight: 4 lbs. (1.83 kg) for non-touch with 56Whr battery; 4.5 lbs. (2.05 kg) for touch with 86Whr battery
Camera:
- 720p at 30 fps HD camera
- Dual-array microphones
Audio and Speakers:
- Studio quality tuning with Waves MaxxAudio® Pro and Waves Nx® 3D audio
- Quad-speaker design with 2.5W x2 woofers and 1.5W x2 tweeters = 8W total peak output
- 3.5mm headphone/microphone combo jack featuring Waves Nx® 3D audio with head-tracking
- Dual microphone array optimized with Waves MaxxVoice supporting VoIP - Microsoft Cortana capable
Chassis:
- CNC machined aluminum in Platinum Silver with carbon fiber composite palm rest in black
- CNC machined aluminum in Frost with Arctic White woven glass fiber palm rest
- Edge-to-edge Corning® Gorilla® Glass 6 on touch panel
Wireless: Killer Wi-Fi 6 AX1650 (2x2) and Bluetooth 5.0
Primary Battery: 6-Cell Battery, 86WHr (Integrated)
