Audio Driver/ Audio Jack
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
For information regarding very common issues, refer to HP Pavilion G60-120US Troubleshooting.
Background and Identification
The HP Pavilion G60-120US (Model Number: FS184UA#ABA) was released in September of 2008. This laptop specialized in providing a 15.6 inch HDTV display as well as a fast wireless LAN connection which enabled users towards completing standard tasks quickly.
The laptop also has a built-in web cam and a microphone and it allows users to video chat without needing an earphone with a mic. Also known for its sleek design as well as comfortability while in use. Other notable features include:
- 3GB RAM
- Altec Lansing Speakers
- HDMI output
- DVD Burner
- 8200M Graphics Card
Specifications
Product Name: G60-120US
Product Number: FS184UA#ABA
Microprocessor: 2.00 GHz AMD Turion X2 RM-70 Dual-Core Mobile Processor
Microprocessor Cache: 1 MB L2 Cache
Memory: 3072 MB
Memory Max: 3072 MB
Video Graphics: NVIDIA GeForce 8200M
Video Memory: Up to 1470 MB
Hard Drive: 250 GB (5400 rpm)
Multimedia Drive: LightScribe SuperMulti 8X DVD±R/RW with Double Layer Support
Display: 15.6" Diagonal High Definition HP Brightview Display (1366x768)
Fax/Modem: High speed 56K modem
Network Card: Integrated 10/100 Ethernet LAN
Wireless Connectivity: Wireless LAN 802.11a/b/g/n WLAN
Sound: Altec Lansing speakers
Keyboard: 101-key compatible with full size keyboard with integrated numeric keypad
Pointing Device: Touch Pad with On/Off button and dedicated vertical scroll Up/Down pad
External Ports
- 5-in-1 integrated Digital Media Reader for Secure Digital cards, MultiMedia cards, Memory Stick, Memory Stick Pro, or xD Picture cards
- 3 Universal Serial Bus USB 2.0
- 1 VGA (15-pin)
- 1 HDMI
- 1 RJ-11 (modem)
- 1 RJ -45 (LAN)
- 1 headphone-out
- 1 microphone-in
Dimensions: 14.88" (L) x 9.9" (D) x 1.38" (min H)/1.61" (max H)
Weight: 6.06 Ibs
Security
- Kensington MicroSaver lock slot
- Power-on password
- Accepts 3rd party security lock devices
Power
- 65 W AC Adapter
- 6-cell Lithium-Ion (Li-Ion)
Source: HP G60-120US Specifications
