Honda EU2200IT A2

The Honda EU2200IT A2 is a portable inverter generator that delivers 2200 Watts of power. The generator includes a Honda GRX120 engine that delivers 200 more Watts of power than the EU2000i model.

The EU2200IT A2 model features a fuel shut-off valve that allows the engine to run while the fuel supply is turned off (mainly to prevent problems related to old or stale fuel). The model also includes a large spout and oil drain gutter for oil changes and increased ventilation to improve airflow through the generator to aid in cooling components.

The generator’s Honda GRX120 engine can run for approximately 3.2 hours at the rated load. The engine operates at 4000 to 4500 revolutions per minute with the ‘Eco Throttle’ function turned off. The generator can hold up to 0.95 gallons of fuel and 14 fluid ounces of engine oil.

The Honda EU2200i series includes the product’s serial number in the bottom corner of the right-hand side of the generator when viewing the product from the front controls face. The generator’s body is red plastic and it includes a grey front face that includes various controls. The name “Honda” is printed in white capital letters on the side and front face of the generator. The model name “EU2200i” is printed in red font on the front of the product.

Model: EU2200i

Serial Number: EAMT 1000001 - 9999999

Engine: GXR120

Displacement:121cc

Compression Ratio: 8.5:1

Engine Speed: 4000 rpm – 4500 rpm (with Eco Throttle^® switch off)

Cooling System: Forced Air

AC Output: 120V / 2200W max. (18.3A); 120 / 1800W rated (15A)

Receptacles: 20A 120V Duplex

DC Output: 12V, 100W (8.3A)

Starting System: Recoil

Fuel Tank Capacity (gal / L): 0.95 US gal / 3.6 L

Engine Oil Capacity (oz. / L): 14 oz. /0.44 L

Run Time per Tankful: 3.2 hours @ rated load; 8.1 hours @ ¼ load

Dimensions (L x W x H - in./mm): 20 inches x 11.4 inches x 16.7 inches / 509 mm x 290 mm x 425 mm

Noise Level: 62 dB @ rated load and 53 dB @ ¼ load

Dry Mass (lbs. / kg): 46.5 lbs. / 21.1 kg

Wet Weight (lbs. / kg): 53.6 lbs. / 24.04 kg

Oil Alert: ^^^^Yes

Ignition System: Full transistor

Eco Throttle^®: Yes

Residential Warranty: 3 Years

Commercial Warranty: 3 Years
