Werkzeuge

Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Background and Identification

The Huawei MediaPad M3 Android tablet was released by Huawei Technologies Co., Ltd in October 2016 as part of the MediaPad series. Huawei is the largest manufacturer of telecommunications equipment in the world. It is also the second-largest smartphone manufacturer, behind only Samsung (Huawei surpassed Apple in 2018). The Huawei MediaPad M3 includes model numbers BTV-DL09, BTV-W09, which are Wi-Fi only and Wi-Fi/3G/4G models. The Huawei MediaPad M3 was released in silver and gold body colors.

The MediaPad M3 features an 8.4-inch screen with a resolution of 1600 by 2560 pixels. Depending on the model, MediaPad M3 tablets include 4 GB of RAM and either 32 GB or 64 GB of internal storage. The tablet also includes a single 8-megapixel main camera and an 8-megapixel selfie camera. Both MediaPad M3 models include a 5100 mAh non-removable battery, meaning their batteries' adhesive is permanent, making repair and replacement more difficult, but not necessarily impossible.

A CNET review of the Huawei MediaPad M3 appreciated the tablet’s aluminum design, fast fingerprint sensor, and loud speakers. The review noted that the Huawei MediaPad M3 tablet is the best Android alternative to the Apple iPad Mini 4.

Huawei tablets include the Huawei logo, which depicts the name “Huawei” in capital letters below a flower-shaped logo on the upper back portion of the tablet. The model information can be found in the lower center of the tablet in small print.

Technical Specifications

Models: BTV-DL09, BTV-W09

Release date: November 2017

Body:

  • Dimensions and Weight: 215.5 x 124.2 x 7.3 mm (8.48 x 4.89 x 0.29 in), 326 g (11.50 oz)
  • SIM: Nano-SIM

Display:

  • Type: IPS LCD capacitive touchscreen, 16M colors
  • Size: 8.4 inches, 204.6 cm2 (~76.4% screen-to-body ratio)
  • Resolution: 1600 x 2560 pixels, 16:10 ratio (~359 ppi density)

Platform:

  • OS: Android 6.0 (Marshmallow), EMUI 4.1
  • Chipset: Kirin 950 (16 nm)
  • CPU: Octa-core (4x2.3 GHz Cortex-A72 & 4x1.8 GHz Cortex A53)
  • GPU: Mali-T880 MP4

Memory:

  • Card slot: microSDXC (dedicated slot)
  • Internal: 32GB 4GB RAM, 64GB 4GB RAM

Main Camera:

  • Single: 8 MP, AF
  • Features: HDR, panorama
  • Video: 1080p@30fps

Selfie Camera:

  • Single: 8 MP
  • Video: 1080p@30fps

Sound:

  • Loudspeaker: Yes, with stereo speakers
  • 3.5 mm jack: Yes
  • Tuned by Harman Kardon

Communications:

  • WLAN: Wi-Fi 802.11 a/b/g/n/ac, hotspot
  • Bluetooth: 4.1, A2DP, EDR, LE
  • GPS: Yes, with A-GPS, GLONASS/ BDS (market dependant)
  • Radio: No
  • USB: micro-USB 2.0

Features:

  • Sensors: Fingerprint (front-mounted), accelerometer, gyro, proximity, compass

Battery:

  • Li-Po 5100 mAh, non-removable

Miscellaneous:

  • Colors: Silver, Gold

Additional Information
