Back Panel
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
If you are having any issues with your device, here is the link to our troubleshooting page.
Lenovo IdeaPad Flex 5-1470 Troubleshooting
Background and Identification
The Lenovo Ideapad Flex 5-1470 (Model number: 81C9000DUS) was first available in February 2017 as a 2 in 1 Laptop that also acted as a tablet. The laptop features an integrated camera with enhanced video communication and microphone, as well as a multi-touch screen and touchpad that functions as a conventional mouse.
The Ideapad is also compatible with the optional Lenovo Active Pen that includes 2 built-in side buttons to provide fast access to apps and functions.
Specifications
Processor:
- CPU: Intel Core I5 (7th Gen) 7200U / 2.5GHz
- Max Turbo Speed: 3.1 GHz
- Number of Cores: Dual-Core
- Cache: 3 MB
- Features: Hyper-Threading Technology, Intel Turbo Boost Technology 2.0, integrated memory controller
Memory:
- RAM: 8 GB (1 x 8 GB)
- Max Supported Size: 16 GB
- Technology: DDR4 SDRAM
- Speed: 2133 MHz
- Form Factor: SO-DIMM 260-pin
Display:
- LCD Backlight Technology: LED backlight
- Widescreen Display: Yes
- Image Aspect Radio: 16:9
- Monitor Features: One Glass Solution, anti-glare
- Touchscreen: Yes (10-point multi-touch)
- Diagonal Size (metric): 35.5 cm
Audio & Video:
- Graphics Processor: Intel HD Graphics 620
- Sound: Stereo speakers, dual array microphone
Battery:
- Capacity: 35 Wh
- Cells: 2-cell
- Technology: lithium ion
- Run Time (Up To): 7 hour(s)
Dimensions:
- Width: 12.9 in
- Depth: 9 in
- Height: 0.8 in
Additional Information
Here are a few links to help you out:
