Werkzeuge

Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Troubleshooting

Figure out a number of problems with your Nikon Coolpix E5700 at the Troubleshooting Page.

Identification and Background

The Nikon Coolpix E5700 is a digital camera utilizing both a digital viewfinder and monitor. These cameras were the first Coolpix to incorporate an electronic viewfinder and use Nikon’s exclusive Extra-lox Dispersion glass for exceptional picture quality. The Nikon Coolpix E5700 cameras are known for unprovoked sensor problems, an issue which prompted Nikon to extend a service advisory. One can determine the model of this camera by the label reading "Nikon E5700" on the bottom of the camera to the right of the tripod mount or the label located left of the lens on the front face reading “Coolpix 5700.” The E5700 is a versatile model with good image quality and numerous features, including:

  • Record images in TIFF-RGB (uncompressed), JPEG or NEF raw
  • Quick Review feature for instant playback
  • Shutter speeds from 1/4000 sec. to 8 secs
  • Programmed Auto (with Shift), Shutter-Priority, Aperture-Priority and Full Manual
  • ISO sensitivity of Auto, 100, 200, 400 or 800
  • Matrix Auto White Balance plus Fine, Incandescent, Fluorescent, Cloudy, Speedlight and Custom Preset

The Nikon Coolpix E5700 was succeeded by the Coolpix 8700, both of which are now discontinued.

Specifications

  • 5-Megapixel CCD for images up to 2560 x 1920 pixels
  • Nikkor 8x zoom (35-280mm in 35mm equivalent) with ED glass
  • Fully articulating 270°, 1.5" color LCD monitor
  • Electronic viewfinder (EVF) with 180,000 pixels
  • CompactFlash Type II card slot (Microdrive compatible)
  • EN-EL1 rechargeable battery and charger included
  • Programmed Auto (with Shift), Shutter-Priority, Aperture-Priority and Full Manual
  • Drive modes: Single, Continuous H, Continuous L, Ultra High Speed Continuous, 16-Shot Multi and QVGA 320x240 Movie with audio @ 15fps up to 60 secs
  • Coolpix-exclusive Best Shot Selector exposure mode
  • Shutter speeds from 1/4000 sec. to 8 secs (Bulb to 5 minutes!)
  • Aperture settings from F2.8 to F10.3 in 10 steps
  • 7-bladed lens diaphram for true depth of field control
  • Control of color saturation intensity
  • Clear Image Mode for highly accurate color, low noise, smooth edged and wide dynamic range images at resolutions of 1280 x 960 and below
  • ISO sensitivity of Auto, 100, 200, 400 or 800
  • Matrix Auto White Balance plus Fine, Incandescent, Fluorescent, Cloudy, Speedlight and Custom Preset.
  • AE Bracketing with white balance and exposure value
  • Built-in flash with auto, fill, slow sync, and red-eye reduction.
  • Hotshoe for external Nikon Speedlights

Additional Information
