Sirius Stiletto 100 Repair

The SL100 is the first portable Sirius radio that allows subscribers to listen to live Sirius programming. The Stiletto boasts a 2 gigabyte memory, which is roughly equivalent to 100 hours of recording time. The unit's batteries give the user approximately 30 hours of life. The unit also features Wi-Fi technology, which is used as a backup to stream music from the Internet when a clear signal strength is not readily available from the built-in antenna. Sirius' partnerships with Napster and Yahoo Music provide additional content for Stiletto users.

Manufacturer: Audiovox / Directed Electronics

The Sirius website offers the Sirius Stiletto SL100 User Guide for additional reference.

Dimensions: 116 mm (height) x 53 mm (width) x 18.25 mm (depth) with Slim Battery --- 116 mm (height) x 53 mm (width) x 25.5 mm (depth) with Standard Battery

Weight: 4.6 oz (132 g) with Slim Battery --- 5.6 oz (158 g) with Standard Battery

Battery Type: 3.7 Volt Lithium Ion

Battery Capacity: Slim Battery: 1320mAh --- Standard Battery: 2740mAh

Internal Memory Capacity: 2 GB NAND Flash

Wi-Fi Standard: 802.11b

Wi-Fi Security: WEP and WPA(2) Personal

Wi-Fi Antenna: Integrated Internal

Internal Antenna Type: Integrated, Low Profile Patch

Audio Interface: 1/8" / 3.5 mm Stereo Jack

Satellite Frequencies: 2322.293/2330.207 MHz

Terrestrial Frequencies: 2326.250MHz

Power Requirements: 5 Volts, 2.0A Negative Ground, DC

Operating Temperature: 23°F to +104°F (-5°C to +40°C)

Headphone Output: 20mW @ 16 ohms

Signal-to-noise (S/N): 90dB (MP3)

See the Troubleshooting Page to gain information on problems encountered with the Sirius Stiletto 100 device and for links to repair guides.
