Werkzeuge

Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Upgrades

Einige Bauteile im iMac Intel 20" EMC 2134 und 2211 können preisgünstig aufgerüstet werden:

  • Speicher: Ab Werk ist der iMac Intel 20" EMC 2134 und 2211 mit 1 oder 2 GB RAM ausgestattet, im EMC 2134 iMacs sind PC2-5300 RAM und im EMC 2211 iMac ein PC2-6400 RAM. Wenn dein iMac noch die ursprüngliche den ursprünglichen RAM drin hat, wird eine Aufrüstung einen dramatischen Leistungsgewinn zu einem günstigen Preis bringen. Der Einbau bis zu 6 GB ist einfach.
  • Festplatte: Als Standard waren 320 GB verbaut. Du kannst bis 2 TB aufrüsten.
  • Hard Drive: 320 GB hard drives came standard with the iMac Intel 24" EMC 2134 and 2211. You can upgrade the drive up to 2 TB.

Identification and Background

You can verify that you have a iMac Intel 20" EMC 2134 and 2211 by checking the processor information through "About This Mac" in the Apple menu.

Use the iMac identification system to help you identify your machine. iMacs tend to look very similar, and it's important to know which machine you have before ordering any replacement parts.

Internally, the iMac Intel 24" EMC 2134 and 2211 were nearly identical to the late 2006 plastic intel iMacs. 2.4, 2.8, and 3.06 GHz Core 2 duo processors and an external graphics card set the performance of EMC 2134 and 2211 iMacs apart from previous generations.

The style of the new aluminum iMacs are a dramatic departure from the white plastic encased iMacs of the past. The aluminum iMacs were to match the design of the original iPhone, both released at nearly the same time. The glass front panel allows for a richer viewing experience, and even with aluminum and glass accents the 20" aluminum iMac is still lighter than all previous 20" iMac generations.

Technical Specs

Measurements:

  • Height 20.5 inches (52.0 cm)
  • Width 22.4 inches (56.9 cm)
  • Depth 8.1 inches (20.7 cm)
  • Weight 25.4 pounds (11.5 kg)

Ports:

  • One FireWire 400 port and one FireWire 800 port; 7 watts each
  • Three USB 2.0 ports
  • Gigabit Ethernet

Wireless Connectivity:

  • Built-in AirPort Extreme Wi-Fi 802.11n wireless networking; IEEE 802.11a/b/g compatible
  • Built-in Bluetooth 2.1

Audio:

  • Built-in stereo speakers with Internal 24-watt digital amplifier
  • Headphone/optical digital audio output (minijack)
  • Audio line in/optical digital audio input (minijack)
  • Built-in microphone

Display:

  • 24-inch glossy widescreen TFT LCD with 1920×1200 resolution

Graphics and video:

  • ATI Radeon HD 2600 PRO graphics processor with 256 MB of GDDR3 memory or NVIDIA GeForce 8800 GS graphics processor with 512 MB of GDDR3 memory
  • Built-in iSight camera

Processor:

2.8 GHz or 3.06 GHz Intel Core 2 Duo processor

Memory:

  • 1 GB (one 1-GB SO-DIMM) or 2 GB (two 1-GB SO-DIMMs) of 800 MHz DDR2 SDRAM; two SO-DIMM slots support up to 6 GB

Storage:

  • 320 GB SATA hard disk drive (7200 RPM)
  • Optional 500 GB, 750 GB, or 1 TB disks
  • DVD/CD Slot-loading 8x SuperDrive
