Battery
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
If you are having difficulties with the ROG G752V try referring to our troubleshooting page.
Background and Identification
The ROG G752V was released in 2016. Its model an be identified by the name Republic of Gamers on topside of the keyboard area. The backside reveals its model number ROG G752V, in which “V” is used to identify different specs.
The ROG G752V, weighing in at a whopping 8.8 pounds, is large, rectangular, metal covered, and is used to handle games that require high computer specification. Differentiating this specific model with other G752 models is difficult because they all share the same design. However, its specific design can be identified by a tag attached to the back. Compared to its previous models, this model has improved battery life, better heat dissipation, and higher performance. This model is equipped with i-7 Intel Core processor and NVIDIA GeForce GTX 1070.
Specification
General
- Manufacturer: Asus
Processor/ Chipset
- CPU: Intel Core i7
- Max Turbo Speed: 3.5 GHz
- Number of Cores: Quad-core
- Cache: 6MB
- Chipset Type: Mobile Intel CM 235 Express
Storage
- Interface: Serial ATA-600
- Optical Drive: DVD RW( R DL)
Memory
- Max Supported Size: 64 GB
- Technology: DDR4 SDRAM
- Speed 2133 MHz/ PC4-17000
- Form Factor SO-DIMM 260-pin
- Slots Quantity: 4
RAM
- Memory Speed: 2133 MHz
- Memory Specification Compliance: PC4-17000
- Technology: DDR4 SDRAM
- Installed Size: 16GB
- Rated Memory Speed: 2133 MHz
Display
- LCD Backlight Technology: LED backlight
- Widescreen Display
- Image Aspect Ratio: 16:9
- Monitor Features: NVIDIA G-SYNC, anti glare
- TFT Technology: IPS
- Diagonal Size: 43.9cm
- Full HD
Audio and Video
- Graphics Processor: NVIDIA Geforce GTX 1070
- Integrated Webcam
- Sound: Stereo speakers, subwoofer, microphone
- Asus Sonic Master
Hard Drive
- Spindle Speed: 7200 rpm
- HDD Size
- Size: 1TB
Battery
- Capacity: 66 Wh
- Cells: 6-cells
- Technology: Lithium Ion
AC Adapter
- Input: AC 120/230 V (50/60Hz)
- Output: 180 Watt, 19.5 V, 9.23 A
System
- Notebook Type: Gaming
- Platform: Windows
Dimensions and Weight
- Width: 16.4 in
- Depth: 12.7 in
- Height: 1.5 in
- Weight: 8.8 lbs
Source: cnet.com Asus ROG-G752V specs
Additional Information
Asus ROG G752VY Disassembly and SSD, RAM, HDD upgrade options
