Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Background and Identification
The Dell Precision M3800 mobile workstation was released to the public in January of 2015. Although, the company does not refer to it as an ultrabook, it fits in the category because it is only 18mm thick, and weighs only 1.88kg because the base frame is made of carbon fiber and aluminum. At the time of release, Dell advertised this laptop as one of the thinnest 15 inch laptops. This laptop was aimed towards content creators and engineers who are looking for a portable computer that can handle running professional software. This computer was perfect for these people because it has a fourth generation Intel Core i7 processor, a battery life over 10 hours, up to 16GB of ram, an mSATA port, and a 2.5-inch HDD.
Sources:
Specifications
Precision Mobile Thin & Light (XPS 15 based) (2015)
Weight: 1.88kg (4.14 lbs)
CPU: 4th generation Intel Core; i7-4712 HQ (4 x 2.3 GHz, 6 MB L3)
Chipset: Mobile Intel HM87 Express
Memory (max): 16 GB DDR3L (2 DIMM slots) 1600 MHz
Graphics: NVIDIA Quadro K1100M (2GB GDDR5 dedicated memory)
Storage Options: Support for two storage devices: one 2.5" drive; one solid state Mini-Card Dell; Fast Response Free Fall Sensor standard
• Hard Disk Drive (HDD): 500GB up to 1TB 2.5” 5400rpm SATA 6Gb/s
• Solid State Hybrid Hard Drive (SSHD): 500GB 2.5” SATA 6Gb/s with 8GB solid state storage
• Solid State Drive (SSD): 256GB or 512GB 2.5” SATA 6Gb/s
• Solid State Mini-Card storage device (mSATA): 128GB, 256GB or 512GB
Screen: 1920x1080 touch, 3840x2160 IGZO touch
Battery Options: 6-cell (61Wh); 6-cell (91Wh)
Source: Dell Precision M3800 Spec Sheet
Troubleshooting
For additional help troubleshooting the Dell Precision M3800 Laptop, check out the troubleshooting page.
