Background and Identification

The Dell Vostro 1520 is a business oriented laptop that was released in mid 2009. This laptop was praised because it was relatively lightweight and offered multiple configurations. This means that the laptop is well suited for everyday consumers and office personnel. The laptop also features an array of touch sensitive, multi-media controls at the top of the keyboard. According to a review by NotebookCheck, the battery can run for about 6 hours without being charged, allowing it to compete against similarly priced laptops.

While the Vostro 1520 offers some strong points, it suffers from screen wobbling when the screen is adjusted. In addition, some users have pointed out that the fan speed fluctuates frequently, making this an annoyance to some. Lastly, some users have reported screen problems such as horizontal pink lines, having a black screen despite the device being powered, and a faulty LCD screen.

This model has it’s series and model number listed near the top of the keyboard, next to the power button. Furthermore, as is typical with Dell laptops, the underside of the device should have a product identification sticker with a service tag which could be used to identify the laptop using Dell’s Support page.

Technical Specifications

CPU

  • Intel Core 2 Duo T6670

Graphics

Integrated

  • Intel GMA 4500MHD

Discrete

  • NVIDIA GeForce 9400M GS

Memory

  • 3GB DDR2 SDRAM 800 MHz

Display

  • 15.4” Anti-glare 1280 x 800
  • Built-in Webcam

Storage

  • 250GB 7200RPM HDD

Battery

  • 6-cell Lithium-ion

Networking & Connectivity

  • Intel Wireless Wi-Fi Link 5100 802.11a/b/g/n + Bluetooth
  • Realtek RTL8168D/8111D

Optical Storage

  • DVD +/- RW (+/- R DL)

I/O Ports

  • 4 x USB 2.0
  • VGA
  • Ethernet
  • 4-pin FireWire
  • Audio out/Headphone
  • 8-in-1 Memory Card Reader

Dimensions & Weight

  • 13.1” x 10.2” x 1.5” (W x D x H)
  • 5.51 lbs.
