MiTM Air Compressors AM1HE0205HD 2014 Safety Precautions
Background and Identification
The Mi-T-M model AM1-HE02-05HD is a five-gallon electric single-stage air compressor with a portable twin tank design designed for remote job sites. An air compressor is a pneumatic device that converts power into potential energy stored in pressurized (compressed) air. The air compressor’s pump features an oil-lubricated aluminum crankcase, a stainless-steel braided discharge hose, and an inlet air filter. It’s motor features thermal overload motor protection. The AM1-HE02-05HD model’s frame includes a powder-coated tank assembly and a protective pump/motor housing. The air compressor includes a regulator and two gauges for tank and outlet pressure. It also features drain and pressure relief valves, as well as industrial interchangeable quick-connect fittings. Its start/stop control is set at 95 to 125 pounds per square inch (PSI).
The AM1-HE02-05HD model air compressor pumps 4.2 cubic feet per minute (CFM) at a pressure of 90 PSI. The motor produces 2.0 horsepower with 120 Volts and 15 Amps.
The AM1-HE02-05HD air compressor includes the name “Mi-T-M” in white font underneath a large beige ‘M.’ The air compressor is mostly black with several stickers including identification information, safety guides, and instructions. The air compressor also includes a black handle for portability. The machine’s motor is placed on the back of the compressor, behind the twin compression tanks.
Technical Specifications
Assembled Depth (in.): 18 in
Assembled Height (in.): 21 in
Assembled Width (in.): 16 in
Weight (lbs.): 61 lbs
CFM @ PSI: 4.2 @ 90
Horsepower/Motor: 2.0 HP, 120V, 15.0 A
Compressor: Single-stage
Cylinder: Cast iron
Plug Type: NEMA 5-15 P
