Troubleshooting

If you are having problems with the Acer Chromebook 15 CB3-532-C47C, try referring to this troubleshooting page.

Background and Identification

The Acer Chromebook 15 cb3-532-c47c is a Chromebook computer sold by Acer. The Acer Chromebook was developed by Acer Inc., a Taiwanese multinational hardware and electronics corporation. They were one of the first to market and began selling them in 2011. The Chromebook is a device that runs a Linux-based Chrome OS as its operating system and most of the data and applications reside in the cloud instead of the machine.

The Acer Chromebook 15 cb3-532-c47c model’s 15.6-inch display has a resolution of 1366 by 768 pixels. It runs on the Intel Celeron N3060 processor with a 2.48 GHz maximum turbo speed. It includes a 2 MB cache and 2 GB of RAM. The provided RAM memory is soldered to the computer’s motherboard, so it is not easily upgradeable. This model features 16 GB of solid-state drive storage. This Chromebook includes a MultiMediaCard/SD Memory Card reader for additional memory. The Acer Chromebook 15 cb3-532-c47c includes an Intel HD Graphics 400 graphics processor. This model includes a 3920 mAh three-cell lithium-polymer battery that is advertised to run up to 12 hours on one charge.

As of now there have been no manufacturer recalls involving this product.

The improvements of this model over similar devices include the large 15.6 inch screen size and long-lasting battery.

The Acer Chromebook 15 cb3-532-c47c includes the name “Acer” printed in lowercase letters in the center of the laptop’s bottom bezel. The computer’s touchpad is centered with the keyboard’s spacebar and the center of the computer’s base. The security lock slot, SD card reader, and one USB port are present on the right side of the chassis, while the other USB port, HDMI port, headphone jack, and power jack are on the left side. The device’s color is granite gray with a matte screen. The service tag with the device’s model number should be visible on the bottom of the laptop for definitive device identification .

Technical Specifications

GENERAL:

  • Operating System: Google Chrome OS
  • Manufacturer: Acer

PROCESSOR / CHIPSET:

  • CPU: Intel Celeron N3060 / 1.6 GHz
  • Max Turbo Speed: 2.48 GHz
  • Number of Cores: Dual-Core
  • Cache: L2 - 2 MB
  • 64-bit Computing: Yes
  • Features: Intel Burst Technology

CACHE MEMORY:

  • Type: L2 cache
  • Installed Size: 2 MB

RAM:

  • Configuration Features: provided memory is soldered
  • Technology: LPDDR3 SDRAM
  • Installed Size: 2 GB

MEMORY:

  • RAM: 2 GB (provided memory is soldered)
  • Technology: LPDDR3 SDRAM

DISPLAY:

  • LCD Backlight Technology: LED backlight
  • Resolution: 1366 x 768 (HD)
  • Widescreen Display: Yes
  • Monitor Features: ComfyView, anti-glare
  • Type: LED
  • Diagonal Size (metric): 39.6 cm
  • Display Resolution Abbreviation: HD

HARD DRIVE:

  • Type: SSD
  • SSD Form Factor: eMMC
  • Capacity: 16 GB

AUDIO & VIDEO:

  • Graphics Processor: Intel HD Graphics 400
  • Memory Allocation Technology: shared video memory (UMA)
  • Integrated Webcam: Yes
  • Sound: Microphone

INPUT:

  • Type: keyboard, touchpad
  • Localization & Layout: US

COMMUNICATIONS:

  • Wireless Protocol: 802.11a/b/g/n/ac, Bluetooth 4.2
  • Wireless Controller: Intel Dual Band Wireless-AC 7265

OPTICAL STORAGE:

  • Drive Type: no optical drive
  • Type: none

PROCESSOR:

  • CPU Type: Celeron
  • Processor Number: N3060
  • Manufacturer: Intel
  • Clock Speed: 1.6 GHz

CARD READER:

  • Type: card reader
  • Supported Flash Memory: MultiMediaCard, SD Memory Card

BATTERY:

  • Capacity: 3920 mAh
  • Cells: 3-cell
  • Technology: lithium polymer
  • Run Time (Up To): 12 hour(s)

AC ADAPTER:

  • Input: AC 120/230 V (50/60 Hz)
  • Output: 45 Watt, 19 V

CONNECTIONS & EXPANSION:

  • Interfaces
    • HDMI
    • 2 x USB 3.0
  • Memory Card Reader: Yes (SD Card, MultiMediaCard)

HEADER:

  • Brand: Acer
  • Product Line: Acer Chromebook 15
  • Model: CB3-532-C47C
  • Country Kits: United States

NETWORKING:

  • Data Link Protocol: Bluetooth 4.2, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
  • Wireless NIC: Intel Dual Band Wireless-AC 7265

MISCELLANEOUS:

  • Color: granite gray
  • Included Accessories: power adapter
  • Theft/Intrusion Protection: security lock slot (cable lock sold separately)
  • Security Slot Type: Kensington security slot

MONITOR:

  • Diagonal Size: 15.6 in
  • Image Brightness: 220 cd/m2

SYSTEM:

  • Notebook Type: Chromebook
  • Platform: Chrome OS
  • Hard Drive Capacity: 16 GB

DIMENSIONS & WEIGHT:

  • Width: 15.1 in
  • Depth: 10.1 in
  • Height: 1 in

PHYSICAL CHARACTERISTICS:

  • Weight: 4.41 lbs

OPERATING SYSTEM / SOFTWARE:

  • OS Provided: Type: Google Chrome OS

VIDEO OUTPUT:

  • Graphics Processor: Intel HD Graphics 400
  • Graphics Processor Series: Intel HD Graphics

VIDEO MEMORY:

  • Memory Allocation Technology: shared video memory (UMA)

NOTEBOOK CAMERA:

  • Integrated Webcam: Yes
