Werkzeuge

Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Troubleshooting

If you are having issues with the Acer Nitro 5 AN515-55-55M1, you can check out the troubleshooting page here!

Background and Identification

The Acer Nitro 5 AN515-55-55M1 is a gaming laptop from Acer that was released in 2020. The top shell and bottom of the display bezel define the device as an "Acer," and the bottom-left sticker on the keyboard deck define the device as a "Nitro 5." The model number can be found on the rear of the device on the sticker near the bottom as "AN515-55-55M1."

The Acer Nitro 5 AN515-55-55M1 is a 15.6" black and red laptop designed for gaming on the go. It is capable of a high refresh rate (144Hz) for a smooth gaming experience. The chassis has remained consistent throughout the Acer Nitro 5 line internally and externally, including this one.

The Acer Nitro 5 AN515-55-55M1 has been superseded by the AN515-55-53E5 in 2021.

Technical Specifications

Operating System:

  • Windows 10 Home

Processor:

  • Manufacturer: Intel
  • Processor Model: Core i5-10300H
  • Processor Speed: 2.50GHz
  • Processor Core: Quad-core

Display/Graphics:

  • Manufacturer: NVIDIA
  • Graphics Controller Model: GeForce GTX 1650
  • Graphics Memory: 4GB GDDR6 Dedicated
  • Screen Size: 15.6"
  • Screen Technology: IPS LCD Full HD, LED Backlight
  • Resolution: 1920 x 1080
  • Refresh Rate: 144Hz

Memory:

  • Memory Capacity: 8GB
  • Memory Technology: DDR4 SDRAM
  • Memory Slots: 2

Storage:

  • Solid State Drive Capacity: 512GB
  • M.2 Slots: 1

Network and Communication:

  • Wireless LAN Standard: IEEE 802.11 a/b/g/n/ac/ax
  • Bluetooth Standard: Bluetooth 5.0

Battery and Power Information:

  • Number of Cells: 4-cell
  • Run Time: 11 Hours
  • Battery Technology: Lithium Ion
  • Maximum Power Supply Wattage: 135 W

Physical Characteristics:

  • Height: 0.94"
  • Weight: 14.3"
  • Depth: 10"
  • Weight: 5.07lbs

Interfaces, Ports, and Devices:

  • Microphone: Yes
  • Finger Print Reader: No
  • HDMI: Yes
  • Number of HDMI Outputs: 1
  • Number of USB 3.2 Gen 1 Type-A Ports: 2
  • Number of USB 3.2 Gen 2 Type-A Ports: 1
  • Number of USB 3.2 Gen 2 Type-C Ports: 1
  • Total Number of USB Ports: 4
  • USB Type-C: Yes
  • USB Type-C Detail: USB Type-C port supporting: USB 3.2 Gen 2 (up to 10 Gbps)
  • Network (RJ-45): Yes

Source to specifications is here.

Additional Information

Acer Nitro 5 AN515-55-55M1 Support Page

Teardown Video of the Acer Nitro 5 AN515-55-55M1

Acer Nitro 5 AN515-55-55M1 Amazon Page
