Asus Eee PC 1005HA

For troubleshooting issues, please visit our troubleshooting guide.

The Asus Eee Pc 1005HA is a netbook that was first manufactured and released by Asus in June of 2009. The Asus Eee Pc 1005HA is available in three models, all of which differ in specifications and price. The three models are the 1005HAB, the 1005HAV, and the 1005HAP. The 1005HAB is the least expensive, with a 3-cell battery that has 4 hour battery life and an Intel Atom N270 central processing unit. the 1005HAP is the most expensive, with a 6-cell battery that boasts a 10.5 hour battery life, and features an Intel Atom N280 processor. The mid line 1005HAV features the weaker Atom N270 processor, but features the larger 6-cell battery.

In both appearance and, in some cases, performance, the 1005HA models are almost identical to their predecessor, the 1008HA. They follow Asus’ “Seashell” design, where the screen hinges to sit behind the base rather than on top of it. Some subtle differences between the two models are that the 1005HA models have the Eee Pc logo on the upper left of the screen, and have uncovered ports, unlike the 1008HA’s plastic coverings. Some models in the 1005HA boast better performance in regards to processing power, RAM, and battery life in comparison to the 1008HA, while others are exactly the same as the 1008HA, with the only difference being the new enclosure of the 1005HA

The best way to identify the 1005HA you have is to turn it over so that the bottom of the computer is facing upwards, and read the serial number, service code, and model type.

Potential Installed Operating Systems

• Genuine Windows® 7 Starter
• Genuine Windows® 7 Home Basic
• Genuine Windows® 7 Home Premium
• Genuine Windows® XP Home
• GNU Linux

Display

• 10.1" LED Backlight WSVGA Screen (1024x600)

CPU & Chipset

• Intel® Atom™ N280/ N270

Memory

• 1GB DDR2 SO-DIMM (Upgradable to 2GB RAM)

Wireless Data Network

• WLAN 802.11b/g/n @2.4GHz
• Bluetooth2.1 + EDR

Storage

• 250GB HDD
• 10GB Eee Storage( XP only)/ 500GB* ASUS * WebStorage (Windows 7 only)

Camera

• 1.3M Pixel or 0.3M Pixel depending on exact SKU

Audio

• Hi-Definition Audio CODEC

Stereo speaker

• Digital Array Mic (XP Only)

Input / Output

• 1 x VGA Port (D-sub 15-pin for external monitor)
• 3 x USB 2.0
• 1 x LAN RJ-45
• 2 x Audio Jack (Head Phone / Mic-in)
• Card Reader: MMC/ SD(SDHC)

Potential Battery Sizes

• 10.5hrs*, 6-Cell 63Wh Li-ion Battery
• 8.5 hrs*, 6-Cell 48Wh Li-ion Battery
• 4 hrs*, 3-Cell 23Wh Li-ion Battery

Dimensions

• 262mm(W) x 178mm(D) x 25.9mm~ 36.5mm(H)

Weight

• 1.27Kg (with 6-Cell Battery)
• 1.1Kg (with 3-Cell Battery)

For more specifications click on the following link

Specifications

Asus: 1005HA

Wikipedia: Eee PC

Specifications
