Battery
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
If you are having issues with your Asus ROG G750JH-DB71 and need additional help, here is the troubleshooting page.
Background
The Asus ROG G750JH-DB71 was released to the world in 2013. Its equipped with a 17.3" full HD LED-Blacklit Display. The screen has a true 16:9 aspect ratio, which is also the standard of HDTVs. The Full HD 1920 x 1080 resolution is supported by a dedicated NVIDIA GeForce GTX 780M graphics card with 4GB of GDDR5 discrete memory.
The laptop weighs about 11 pounds, and is fairly large compared to other laptops. It is a laptop designed for playing video games, and thus has very powerful parts that can run intensive software. The laptop was fairly well received, currently having a 4.5/5 stars on B&H. It had no major callbacks in its lifetime, with a couple of issues occurring due to the device's software (Windows 8) rather than its hardware.
The system is powered by a quad-core 4th-generaton Haswell 2.4GHz Intel Core i7-4700HQ processor. It also has 24GB of 1600MHz DDR3L RAM, a 1TB 5400rpm hard drive, dual 128GB solid state drives for a total of 256GB, a Blu-ray Disc reader, a multi-format media card reader, 10/100/1000Mbps Gigabit Ethernet, 802.11a/b/g/n Wi-Fi, Bluetooth 4.0, an integrated webcam and microphone. The built-in stereo speakers and subwoofer utilize SonicMaster technology and support MaxxAudio.
Windows 8 (64-bit) is the installed operating system. Windows 8 replaces the traditional Start menu with a redesigned Start screen. The Start screen features tiles, which provide notifications in real-time. Windows 8 also focuses more on cloud storage as well as apps, which can be downloaded from the Windows Store. Windows 8 provides a unique user experience that differs from previous versions of Windows.
Identification
The Asus ROG G750 is a black bulky laptop. It has the Asus and ROG logos on the top of it, along with the ROG logo beneath the keyboard and the Asus logo beneath the screen itself. The interior is covered by a black plastic with a line texture on it, while the exterior is covered by a solid black plastic.
Dimensions
Width - 410 mm
Depth - 318
Height (Front) - 1.8 cm
Height (Rear) - 8.8 cm
Weight
4.8 kg
Technical Specifications
Battery
8 Cell Lithium Ion
Battery Capacity - 5900 mAh
I/O Ports and Devices
4 USB 3.2 Gen 1 type A port
1 Ethernet LAN (RJ-45) port
1 HDMI port
1 VGA(D-Sub) port
1 thunderbolt port
1 headphone output
S/PDIF out port
1 Microphone in
Charging port type (DC in Jack)
1 Blueray Disk Drive
CPU
Intel® Core™ i7 i7-4700HQ 2.4 GHz
Storage
1256 GB HDD + SSD
RAM
12 GB DDR3-SDRAM
GPU
NVIDIA® GeForce® GTX 780M 4 GB Intel® HD Graphics 4600
Power Consumption
230 W Maximum (60 Low)
