Epson Home Cinema 2150 Repair

This troubleshooting page will aid in the diagnosis of any problems pertaining to the Epson Home Cinema 2150

The Epson Home Cinema 2150 was first introduced back in 2017 as a home entertainment projector for family use. Epson Home Cinema 2150 was made to emit bright light and colorful images for display, this device does not display the DLP rainbows that most projectors do, projecting images clearly for the viewers. The Epson Home Cinema 2150 has a wide zoom range, which allows it to be placed at a considerable distance from the desired canvas, up to 11 feet or more. The Epson Home Cinema 2150 can withstand and project the 1080p/60 image or footage and play 3D movies. This projector is wireless allowing it to connect with any device capable of blue-tooth and project sound through the set of speakers included. The lifetime of this projector’s lamp is approximately 4500 hours in normal mode and up to 7500 in its specialized Eco mode.

The Epson Home Cinema 2150 is a bright high resolution projection system. It supports wireless connectivity, a wireless remote control, HDMI connection cable, mac and windows software. Its Lens is located in the front, the lamp cover is located at the back top left side of the projector, air-filter intake vent and cover is located on the right side of the projector and directly opposite to that is the exhaust vent. At the back of the vent  we can locate all the connection types included such as: AC Input, Speaker, Remote control receiver, HDMI port 1 and 2, PC port and USB Type A port. Finally the control panel which can be located at the top and includes: the wireless LAN, status light, power button, home button, menu button, enter button, escape (esc)  button, source button and the volume. Finally the model number is located at the bottom of the device.

• Projector Size: 4.80” x 12.20” x 11.20” (HxWxD)
• Weight: 7.7 lbs
• Audible Noise: 37dB/ 29 dB (eco)
• Internal Speakers: 10.00 Watts Mono
• Power: 312 Watts 100 V - 240 V
• Connection Panel:
  • Audio Out Mini Jack
  • USB
  • HDMI
  • VGA In: Dsub -15pin
  • HDMI (MHL)
  • Wireless Networking
• Features:
  • Full HD 3D
  • Frame Interpolation
  • Geometric Correction
  • Miracast
• Native Resolution: 1080p (1920 x 1080)
• Color Brightness: 2500 lumens
• White Brightness: 2500 lumens
• Aspect Ratio: Native 16:9 widescreen
• Contrast: up to  60,000:1
• Display Type: 3LCD, 3 - chip technology
• Display Performance: 1920 x 1080 native 1080p; HD, 2D, 3D
• Color Processing: Full 10 bits
• Size projected distance: 30”-300” at (2.86 ft - 29.2 ft)
• Throw Ratio Range: 1:33 (Zoom Wide) - 2.16 (Zoom: Tele)
• Color Modes: Dynamic, Bright Cinema, Natural, Cinema, 3D Dynamic, 3D Cinema

• Lamp Type: 200 W UHE
• Lamp Life: 4000 hours of normal life and 7500 with ECO mode
• Lamp Model: ELPLP96/V13H010L96

• Lens Shift: Manual
• Focal Length: 18.2-29.2 mm
• Zoom Ratio: 1.0-1.6x manual

Source: Epson Home Cinema 2150 Wireless Specifications
