Lenovo ThinkPad X1 Yoga 2nd Generation Repair

Identify problems with your device using this Lenovo ThinkPad X1 Yoga 2nd Generation Troubleshooting guide.

The Lenovo ThinkPad X1 Yoga 2nd Generation (Model number: TP00076C), released in April 2017, is a convertible-hybrid laptop built to switch between Laptop Mode and Tablet Mode. It is marketed as a business laptop with features that appeals to needs ranging from casual office work to travel. Compared to the 1st Generation model, the Thinkpad X1 Yoga 2nd Generation features an improved processor, graphics, and longer battery life. Key parts of the laptop include the following: a rise-and-fall keyboard when switching between modes, rechargeable pen, and rapid charging battery.

The laptop comes in black or silver and can be identified as the 2nd Generation model by the text on the back. It is slim with dimensions of 13.11" x 9.02" and lightweight at 3 lbs. Other identifying features include the fingerprint scanner to the right of the touchpad and the rechargeable pen in its slot on the right side of the device.

The Lenovo ThinkPad X1 Yoga 2nd Generation has since been replaced by the 3rd and 4th Generation models, which feature improved technical specifications while still retaining the best features of the 2nd Generation.

Processor:

• 7th Generation Intel® Core™ i7-7600U Processor with vPro™ (2.80GHz, up to 3.90GHz with Turbo Boost, 4MB Cache)

Operating System:

• Windows 10 Pro

Display:

• 14" FHD (1920 x 1080)

Touch Screen:

• Standard

Graphics:

• Integrated Intel® HD Graphics 620

Memory:

• 8 GB LPDDR3 1866 MHz

Storage:

• 256 GB PCIe SSD OPAL2.0

Battery:

• Up to 15 hours

Camera:

• 720 HD Camera with microphone

Audio:

• Dolby Audio™ Premium

Stylus Pen:

• ThinkPad Pen Pro

Security:

• dTPM 2.0
• Touch Fingerprint Reader

Input/Output Ports:

• 2 Intel® Thunderbolt™ 3
• 3 USB 3.0
• HDMI
• Mini-RJ45
• MicroSD
• MicroSIM

Connectivity:

• Intel® Dual Band 8265 Wireless AC (2 x 2)
• Bluetooth® 4.1 with vPro™
• WWAN: Sierra Wireless EM7455 4G LTE-A

Dimensions (WxDxH):

• 333 x 229 x 17 mm (13.11" x 9.02" x 0.67")

Weight:

• 1.36 kg (3 lbs)
