Werkzeuge

Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Troubleshooting

Start diagnosing your hardware problems using the Dell Inspiron 15-7537 troubleshooting guide.

Identification and Background

The Dell Inspiron 15-7537 is a touchscreen laptop released in 2013. Weighing at 5.73 lbs, it is equipped with a sleek aluminum exterior and a display covered in Corning Gorilla Glass to protect from scratches. This is a particularly durable laptop that can withstand short-term heat exposure. This notebook comes in three models: one with a core i5 processor, and the other two with an i7 processor. In terms of storage, different options in size and type exist, including solid state drives and hard drives.

There have been no factory recalls on this model. However, older models have had issues with the Intel WiFi card.

You can identify this machine by its model number located on the bottom of the laptop. An example model number is P36F.

Technical Specs

Battery

  • 4-cell battery
  • 14.8 VDC
  • Batter life: 6 hours

Operating System

  • Windows 8

Weight

  • 5.73 lbs.

Dimensions

  • 14.94" x 10.03"

Connectivity

  • 10/100/1000 Mbps Ethernet LAN on Motherboard
  • Intel Wireless-N7260
  • Wi-FI 802.11 b/g/n
  • Bluetooth 4.0

Display

  • 15.6" LED Touch Display

Performance

  • 4th Gen Intel Core i5-4200U processor
  • Integrated Graphics

Memory

  • 6GB Memory (up to 16GB)

Hard Drive

  • 750GB Hard Drive
  • 7200 RPM

Ports and Connectors

  • Audio port
  • HDMI
  • 3 usb 3.0
  • 1 usb 3.0 with PowerShare
  • 1 RJ45 port

Video

  • Intel HD Graphics 4400
  • System shared memory

Camera

  • 0.92 megapixels
  • Maximum video 1280x720 (HD) at 30 fps

Audio

  • 2 two-Watt speakers

Additional Information
