Werkzeuge

Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Background and Identification

The Dewalt model DCN660D1 is a 16-gauge cordless angled finish nailer produced by Dewalt. Dewalt is an American manufacturer of power tools and hand tools for the construction, manufacturing, and woodworking industries. The nailer drives 16-gauge angled finish nails between 1-1/4 inch and 2-1/2 inch long. It is compatible with all Dewalt 20-Volt MAX batteries and chargers. The Dewalt 20-Volt MAX line includes over 200 products, all with interchangeable batteries and chargers. The nailer can be used for finish applications including trim installation.

The Dewalt model DCN660D1 includes a sequential mode for precision placement and a bump mode for production speed. It can staple up to 800 nails per charge with a 20-Volt MAX 2.0-Amp-hour battery. Other Dewalt 20-Volt MAX batteries have larger Amp-hour values, so they can run longer with this stapler. The stapler includes multi-functional lights that provide both workspace illumination and tool diagnostics. Users can adjust the nail countersink depth without the use of other tools.

The Dewalt model DCN660D1 nailer can be identified by its yellow body with black accents. The name “Dewalt” is printed in black capital letters with the words “20V MAX” underneath on the side of the nailer’s main body. The words “16 GA” is engraved in the side of the nailer, indicating that the nailer uses 16 gauge nails.

Technical Specifications

Dimensions:

  • Product Depth (in.): 18.5
  • Product Height (in.): 15.563
  • Product Width (in.): 7.7

Details:

  • Air Tool Type: Air Nailer Kit
  • Battery Amp Hours: 2 Ah
  • Battery/Charger: (1) 2 Ah Battery & Charger Included
  • Charger Included
  • Cordless/ Corded: Cordless
  • Included: Bag, Battery, Battery Charger
  • Maximum Fastener Size: 2-1/2 in
  • Minimum Fastener Size: 1-1/4 in
  • Motor Type: Brushless
  • Nail Gauge: 16
  • Nailgun Angle: 20
  • Number of Total Batteries Included: 1
  • Power Type: Cordless Electric
  • Tools Product Type: Air Tool Kit
