Background

The HAMILTON-G5 was designed for the most complex, critically ill patients in all ICU settings where lung protection is of paramount importance.

The comprehensive monitoring package and state-of-the-art diagnostic tools for lung assessment support you in making the best possible clinical decisions for your patient.

A wide range of additional options and features, such as Heliox, allows you to tailor the HAMILTON-G5 to fit the requirements of your ICU and meet the needs of each individual patient.

Specifications

General

  • Adjustable O2 enrichment
  • Capnography, mainstream (volumetric) and sidestream- Optional
  • Distributed alarm system (DAS) compatible
  • Dynamic Lung (real-time visualization of the lungs)
  • Event log (up to 1000 events with date and time stamp)
  • Humidifier Control- Optional
  • Inspiratory and expiratory hold maneuver
  • IntelliTrig (leak compensation)

Automatic expiratory base flow

  • Pressure trigger: 1 l/min
  • Flow trigger setting ≤ 2 l/min: 4 l/min
  • Flow trigger setting > 2 l/min

Inspiratory pressure

  • 0 to 120 cmH2O

Maximum inspiratory flow

  • 180 l/min peak flow max
  • 120 l/min continuous flow

Tidal Volume

  • Adult/Ped: 20 to 2000 ml
  • Neonatal: 2 to 200 ml

Communication Ports

  • CompactFlash
  • USB
  • DVI
  • COM (RS-232)
  • Special interface

Pneumatic specifications

  • O2 Input pressure: 2 to 6 bar / 29 to 87 psi
  • Air supply Input pressure: 2.8 to 6 bar / 41 to 87 psi
  • Heliox Input pressure 2.8 to 6 bar / 41 to 87 psi

Electrical specifications

  • Input power: 100 to 240 VAC ±10%, 50/60 Hz
  • Power consumption: 210 VA maximum
  • Battery: 12 V DC, 15 Ah
