Troubleshooting

Find solutions to common issues with the Lenovo ThinkPad X390 here.

Background Information

The ThinkPad X390 is a business laptop by Lenovo. The Laptop’s 12” footprint and lightweight build make it an excellent choice for travel. PrivacyGuard comes standard on all Lenovo ThinkPad X390’s making the screen impossible to view from any angle other than straight-on, keeping your data safe. Despite it’s lightweight and thin frame, the ThinkPad X390 packs-a-punch with it’s 8th generation Core i7 or 10th generation Core i5 intel processors, making it a suitable workhorse for any profession.

This device features either a 10th Generation Intel® Core™ i5-10210U Processor or a 8th Generation Intel® Core™ i7-8665U Processor, 13.3” anti-glare screen, and a 720p webcam located at the top of the monitors bezel. This model is easily mistakeable for Lenovo ThinkPad X390 Yoga. Unlike the The Lenovo ThinkPad X390 Yoga, this model features traditional hinges that limit the monitors ability open, whereas the yoga is able to open up to a full 360-degrees with its hinges.

Specifications

Processor:

  • 8th Generation Intel® Core™ i7-8665U Processor with vPro™ (1.90 GHz, up to 4.80 GHz with Turbo Boost, 4 Cores, 8 Threads, 8 MB Cache)
  • 10th Generation Intel® Core™ i5-10210U Processor (1.60 GHz, up to 4.20 GHz with Turbo Boost, 4 Cores, 8 Threads, 6 MB Cache)

Operating System:

  • Windows 10 Pro 64

Display:

  • 13.3" FHD (1920 x 1080) IPS, anti-glare, 300 nits
  • 13.3" FHD (1920 x 1080) IPS, anti-glare, touchscreen, 300 nits

Graphics:

  • Integrated Intel® UHD Graphics

Battery:

  • Up to 17.6 hours with 48 Whr battery

Memory:

  • 16 GB DDR4 2400MHz (Soldered)
  • 8 GB DDR4 2667MHz (Soldered)

Storage:

  • Up to 512 GB PCIe SSD

I/O Ports:

  • 2 x USB 3.1 Gen 1** (one Always On)
  • 1 x USB 3.1 Gen 1 Type-C (Power Delivery, DisplayPort, Data transfer)
  • 1 x USB 3.1 Gen 2 Type-C / Intel Thunderbolt 3 (Power Delivery, DisplayPort, Data transfer)
  • MicroSD card reader/Micro-SIM combination slot
  • Smart card reader (Optional)
  • Headphone / mic combo
  • HDMI 1.4
  • RJ45 via Ethernet Extension adapter (sold separately)

Connectivity:

  • Intel® 9560 802.11AC (2 x 2) & Bluetooth® 5.1
  • Intel® 9560 802.11AC (2 x 2) & Bluetooth® 5.1 with vPro

Webcam:

  • 720p HD

Audio:

  • Dolby Audio Premium
  • Dual far-field microphones

Dimensions (WxDxH):

  • 12.3" x 8.6" x 0.67" / 311.9 x 217.2 x 16.9 (mm)

Weight:

  • Starting at 2.84 lbs (1.28 kg)

Source: ThinkPad X390 (13”) Laptop Tech Specs
